Aver MT300N Dubai

Aver MT300N Dubai

The Aver MT300N Dubai opens up new possibilities by integrating AVer Pro AV cameras in collaborative environments. It is a small, versatile device that supports Voice Tracking in various room types without the need for expensive in-room PCs or servers running PTZ Link software.

Category:

Description

Aver MT300N Dubai

The Aver MT300N Dubai opens up new possibilities by integrating AVer Pro AV cameras in collaborative environments. It is a small, versatile device that supports Voice Tracking in various room types without the need for expensive in-room PCs or servers running PTZ Link software. It is compatible with third-party microphones and allows for customizable multi-camera switching. The device also enables seamless integration for capture and collaboration with its USB, NDI|HX2, HDMI, and H.264 input and output connectivity.

Integrated voice tracking

  •  Pre-installed PTZ Link software works with AVer Pro AV cameras and 3rd-party microphone systems including Sennheiser, Shure, Yamaha, Nureva, ClearOne, and Audio-Technica.Create a multi-camera feel across all your preset zones.

Multi-camera switching

  • Premium Version of PTZ Link license supports up to five groups of AVer cameras and microphones to accomplish automatic video switching.
  • Access direct connectivity to AVer cameras via USB.
  • Rich video conferencing platform compatibility allows you to switch cameras between Microsoft Teams, Zoom Room or Google Meet systems.
  • BYOD (Bring your own device) or integrate it with your existing devices, while leveraging its multimedia capabilities.

Web UI with Remote Management

  • Our simple web-based interface enables convenient remote access and management of cameras.
  • Additionally, users can effortlessly create personalized profiles including display layouts to easily access their preferred settings.

Advanced Motion Control

  • Take advantage of the power of NDI|HX2 format with built-in encode support for your connected devices.

Compact. Easily mountable

  • The small form factor allows you to neatly tuck away the MT300N under a desk with the rack mount brackets (included) or on a server rack with the optional server rack mount (sold separately).

Specifications

  • Platform  Embedded Linux on Quad Core ARM®
  • Input Resolutions  1080p/60, 1080p/59.94, 1080p/50, 1080p/30, 1080p/29.97, 1080p/25, 1080i/60, 1080i/59.94, 1080i/50, 720p/60, 720p/59.94, 720p/50
  • Output Resolution
  • HDMI Outputs
    • 2160p/60, 2160p/59.94, 2160p/50, 2160p/30, 2160p/29.97, 2160p/25, 1080p/60, 1080p/59.94, 1080p/50, 1080p/30, 1080p/29.97, 1080p/25,
    • 1080i/60, 1080i/59.94, 1080i/50, 720p/60, 720p/59.94, 720p/50, 480p/60
  • USB Outputs
    • YUY2 1080p/30, 1080p/15
    • MJPEG 2180p/30, 2180p/15, 1080p/60, 1080p/30
  • Stream Output
    • Resolution 3840×2160, 1920×1080, 1280×720, 960×540, 640×480, 640×360
    • Framerate 1, 5, 15, 20, 30, 60
  • Camera Control – Protocols VISCA (RS-422 / IP), PELCO-D & PELCO-P (RS-422), CGI (IP)
  • Maximum Input Signals 7
  • Maximum Output Signals 1
  • Video Output  All outputs are mirrored HDMI (2), IP, USB 3.0 Type-A (2), NDI HX2
  • Video Input  HDMI (3), IP, NDI HX3, USB 2.0 Type-B (3)
  • Camera Control – Interfaces  RS-422 (RJ45), IP
  • Ethernet  RJ45 (2), PoE+ – Port 1 only
  • Buttons  Power, Reset (recessed)
  • Resolution Up to 2180p/60 (Maximum decode resolution upto 1080p/60)
  • Network Video Compress Formats H.264, H.265, MJPEG
  • Maximum Frame Rate 60fps
  • Bit-Rate Control Modes  VBR, CBR (selectable)
  • Range of Bit-Rate Setting  512 Kbps to 32 Mbps, and Auto
  • Network Interface  10 / 100 / 1000 Base-T
  • Network Protocols   IPv4, TCP, UDP, ARP, ICMP, IGMP, HTTP, HTTPS, DHCP, RTP / RTCP, RTSP, RTMP, SRT, HLS, NDI, LLDP, VISCA over IP
