Description
Cisco Catalyst9130AXE Dubai
The Cisco Catalyst9130AXE Dubai Series Access Points offer a seamless experience across various network deployments, ensuring high scalability and unparalleled performance. Surpassing the Wi-Fi 6 (802.11ax) standard, the 9130AXE Series integrates security, resilience, and operational flexibility, along with heightened network intelligence.
An extension of Cisco’s intent-based network and suitable for networks of all sizes, the Cisco Catalyst9130AX Dubai accommodates the increasing demands of IoT while fully embracing the latest innovations and emerging technologies. The 9130AXE Series stands out as a frontrunner in terms of performance, security, and analytics.
Paired with the Cisco Digital Network Architecture (Cisco DNA), the Cisco Catalyst9130AXE Dubai Access Points represent enterprise-class solutions catering to both existing and future needs. Serving as the initial step in modernizing your network, these access points enable you to fully leverage all the features and benefits offered by Wi-Fi 6.
The Cisco Catalyst9130AXE Dubai Access Points support both Orthogonal Frequency-Division Multiple Access (OFDMA) and multiuser multiple input, multiple output (MU-MIMO), ensuring more predictable performance for advanced applications and IoT. Additionally, with speeds of up to 5 Gbps and NBASE-T and IEEE 802.3bz Ethernet compatibility, the 9130 Series seamlessly offloads network traffic without encountering any bottlenecks.
Features :
- Next-generation Wi-Fi 6 (802.11ax) access points with 4×4 Multiple-Input Multiple-Output (MIMO) and four spatial streams :
- 8×8 :8 single or dual 4×4 :4 on 5 GHz and downlink/uplink Orthogonal Frequency-Division Multiple Access (OFDMA)
- 4×4 :4 on 2.4 GHz with multiuser MIMO (MU-MIMO) and downlink/uplink OFDMA
- Cisco DNA ready
- Cisco RF Application-Specific Integrated Circuit (ASIC) with next-generation Cisco CleanAir and upgradable RF features
- Built-in Bluetooth Low Energy (BLE) radio (Bluetooth 5.0)
- Multigigabit Ethernet (1 Gbps, 2.5 and 5 Gbps)
- USB
- Supports up to 500 Wi-Fi devices
- IoT ready (Zigbee, Thread)
- Internal and external antenna options
- Operating temperature for 9130I : -32° to 122°F (0° to 50°C)
- Operating temperature for 9130E : -4° to 122°F (-20° to 50°C)
Technical Specs
| Internet of Things (IoT) | |
| Internet of Things (IoT) Compatible | Yes |
| Communications Technology | Bluetooth Low Energy (LE), Zigbee |
| Miscellaneous | |
| Included Accessories | Low profile bracket, ceiling grid clip |
| Compliant Standards | CISPR 24, EN 61000-3-2, ICES-003, EN 61000-3-3, EN55024, FCC Part 15.247, AS/NZS 60950-1, RSS-102, UL 2043, UL 60950-1, IEC 60950-1, EN 60950-1, AS/NZS 4268, FCC Part 15.407, FCC CFR47 Part 15 C, FCC CFR47 Part 15 B, EN 62209-1, SRRC, EN 50385, EN 62209-2, EN 301 489-1, LP0002, RSS-247, KN32, KN35, AS/NZS CISPR 32 Class B, CISPR 32, EN 55032, EN 61000-6-1:2007, EN 60601-1-2:2015, CAN/CSA-C22.2 No. 60950-1, EN 300 328 V2.1.1, EN 55035, VCCI-CISPR 32:2016, CNS, EN 301 489-17, AS/NZS 2772, ARPANSA, KN 61000-3-2, KN 61000-3-3, KN 489-1, QCVN, KN 489-17, RSP-100, RSS-GEN, EN 301 893 V2.1.1 |
| Networking | |
| Form Factor | External |
| Connectivity Technology | Wireless |
| Line Coding Format | OFDMA |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 5 Gigabit Ethernet, 2.5 Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6) |
| Spread Spectrum Method | OFDMA |
| Frequency Band | 2.4 GHz, 5 GHz |
| Status Indicators | Status |
| Features | LLDP support, Maximum Ratio Combining (MRC), Wireless Intrusion Prevention System (WIPS), 802.1x authentication, cyclic shift diversity (CSD), MU-MIMO technology, packet aggregation A-MPDU, packet aggregation A-MSDU, Dynamic Frequency Selection (DFS), secure boot, 8×8 MU-MIMO technology, Target Wait Time (TWT), Cisco Trust Anchor module, 4×4 MIMO technology |
| Encryption Algorithm | AES, TLS, PEAP, TTLS, WPA2, EAP-SIM, WPA3, EAP-FAST |
| Authentication Method | MS-CHAP v.2, Extensible Authentication Protocol (EAP), EAP-FAST, EAP-SIM |
| Compliant Standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11d, IEEE 802.11g, IEEE 802.1x, IEEE 802.11i, IEEE 802.11h, IEEE 802.11n, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az, IEEE 802.15.4, IEEE 802.11ac, IEEE 802.3bz, IEEE 802.3bt, IEEE 802.11ax, Wi-Fi CERTIFIED 6 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty – lifetime |
| Environmental Parameters | |
| Min Operating Temperature | -4 °F |
| Max Operating Temperature | 122 °F |
| Humidity Range Operating | 10 – 90% (non-condensing) |
| General | |
| Device Type | Wireless access point |
| Ruggedized Design | Indoor |
| Width | 9.2 in |
| Depth | 9.2 in |
| Height | 1.6 in |
| Weight | 3.77 lbs |
| Localization | Puerto Rico, United States |
| Processor / Memory / Storage | |
| RAM | 2 GB |
| Flash Memory | 1 GB |
| Expansion / Connectivity | |
| Interfaces |
|
| Power | |
| Power Over Ethernet (PoE) Supported | UPOE |
| Antenna | |
| Antenna | External |
| Software / System Requirements | |
| Software Included | Cisco Embedded Wireless Controller software image |
