Description

Cisco SF500-48P Dubai

The Cisco SF500-48P Dubai switch safeguards your technology investment as your business expands. Unlike purportedly stackable switches with separately managed elements, the Cisco SF500-48P Dubai offers genuine stacking capability, empowering you to configure, manage, and troubleshoot multiple physical switches as a unified device, simplifying network expansion. Notably, select models in the Cisco 500 Series switch line feature fanless designs, distinguishing them as pioneers in the stackable switch industry. This innovation ensures heightened reliability, improved power efficiency, and minimized noise.

With a unified data and control plane, along with a management plane, genuine stacking facilitates enhanced flexibility, scalability, and user-friendliness, as the stack of units operates as a cohesive single entity, encompassing all ports of the stack members. Moreover, the Cisco SF500-48P Dubai switch fortifies your technology investment with an extended warranty, dedicated technical support, and the potential for future equipment upgrades, including the option to receive credit for your Cisco 500 Series switch. Overall, the Cisco SF500-48P Dubai serves as the optimal technology foundation for a thriving business.

The Cisco SF500-48P Dubai Stackable Managed Switch represents a novel line of stackable managed Ethernet switches that furnish the advanced capabilities necessary for supporting a more demanding network environment, all at a reasonable price point. These switches provide 24 or 48 ports of Fast Ethernet and 24 to 52 ports of Gigabit Ethernet connectivity, with optional 10 Gigabit uplinks, establishing a robust foundation for your existing business applications and future plans. Moreover, these switches are straightforward to deploy and manage, eliminating the need for a large IT staff.

Features

Simple Deployment and Use Cisco

Cisco SF500-48P Dubai switch is designed to be easy to use and manage by small businesses or the partners that serve them. It has the following features:

• Simple-to-use graphical interfaces reduce the time required to deploy, troubleshoot, and manage the network and allow you to support sophisticated capabilities without increasing IT head count.
• You can manage the switches as individual devices or use Cisco Configuration Assistant (CCA) to discover, configure, and manage all Cisco devices in the network.
• The Cisco SF500-48P Dubai support Textview, a full command-line interface (CLI) option for partners that prefer it.
• Using Auto Smartports intelligence, the switch can detect a network device connected to any port and automatically configure the optimal security, quality of service (QoS), and availability on that port.
• Cisco Discovery Protocol (CDP) discovers Cisco devices and allows devices to share critical configuration information, simplifying network setup and integration.
• Support for Simple Network Management Protocol (SNMP) allows you to set up and manage your switches and other Cisco devices remotely from a network management station, improving IT workflow and mass configurations.
• The Cisco FindIT utility, which works through a simple toolbar on the user’s web browser, discovers Cisco devices in the network and displays basic information, such as serial numbers and IP addresses, to aid in configuration and deployment. (For more information, and to download this free utility, please visit www.cisco.com/go/findit.)

High Reliability and Resiliency

In a growing business where 24×7 availability is critical, you need to assure that employees can always access the data and resources they need. In these environments, stackable switches can play an important role in eliminating downtime and improving network resiliency. For example, if a switch within a Cisco SF500-48P Dubai switch stack fails, another switch immediately takes over, keeping your network up and running. You can also replace individual devices in the stack without taking your network offline or affecting employee productivity.

The Cisco SF500-48P Dubai switch provide an additional layer of resiliency with support for the Virtual Router Redundancy Protocol (VRRP). VRRP lets you extend the same resiliency that stacking provides for individual switches to complete network domains. By running VRRP between two stacks, you can instantly cut over from one stack to another in the event of a problem, and continue operating even after a failure. The Cisco SF500-48P Dubai switch also supports dual images, allowing you to perform software upgrades without having to take the network offline or worry about the network going down during the upgrade.

Simplified IT Operation

The Cisco SF500-48P Dubai switch helps optimize your IT operations with built-in features that simplify and streamline day-to-day network operation:

• True stacking allows you to troubleshoot, configure, and manage multiple physical switches as a single entity.
• Unlike other stacking switches that require uniform configurations, Cisco SF500-48P Dubai allows you to mix Fast Ethernet, Gigabit Ethernet, and 10 Gigabit Ethernet models in a single stack, providing total flexibility without sacrificing manageability.
• Cisco switches use common chipsets/software across all switching portfolios, so all Cisco switches within a category support the same feature set – making it easier to manage and support all switches across the network.

True Stacking

A true stack delivers a unified data and control plane, in addition to management plane, providing flexibility, scalability, and ease of use since the stack of units operate as a single entity constituting all the ports of the stack members. This capability can radically reduce complexity in a growing network environment while improving the resiliency and availability of network applications. True stacking also provides other cost savings and administrative benefits through features such as cross-stack QoS, VLANs, and port mirroring, which clustered switches can’t support.

Strong Security

Cisco SF500-48P Dubai provides the advanced security features you need to protect your business data and keep unauthorized users off the network:

• Embedded Secure Sockets Layer (SSL) encryption protects management data traveling to and from the switch.
• Extensive access control lists (ACLs) restrict sensitive portions of the network to keep out unauthorized users and guard against network attacks.
• Guest VLANs let you provide Internet connectivity to nonemployee users while isolating critical business services from guest traffic.
• Support for advanced network security applications such as IEEE 802.1X port security tightly limits access to specific segments of your network. © 2011–2012 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 4 of 16 Data Sheet
• Advanced defense mechanisms, including dynamic Address Resolution Protocol (ARP) inspection, IP Source Guard, and Dynamic Host Configuration Protocol (DHCP) snooping, detect and block deliberate network attacks. Combinations of these protocols are also referred to as IPMB (IP-MACport binding)
• Time based VLANs restrict access to the network during predesignated times, such as business hours.
• Uniform MAC address-based security can be applied automatically to mobile users as they roam between wireless access points.
• Secure Core Technology (SCT) helps ensure that the switch is able to process management traffic in the face of a denial of service attack.
• Private VLAN Edge (PVE) provides Layer 2 isolation between devices on the same VLAN.
• Storm control can be applied to broadcast, multicast, and unknown unicast traffic.
