Description
Cisco SG550XG-24F Dubai
The Cisco SG550XG-24F Dubai showcases a next-generation stackable managed Ethernet switch engineered to offer advanced capabilities and superior performance essential for supporting a more demanding network environment, all at an accessible price point. With its provision of 10 Gigabit Ethernet and advanced capabilities, it facilitates the acceleration of your business growth. This next-generation stackable managed switch, the Cisco SG550XG-24F Dubai, delivers immediate productivity gains to your organization and prepares your network for the impending influx of bandwidth-hungry applications in the future. The integration of fan and power hardware redundancy effectively enhances overall network availability, while the user-friendly deployment and management of the Cisco SG550XG-24F Dubai ensure seamless operation without the need for an extensive IT team.
Engineered to safeguard your technological investments as your business expands, the Cisco SG550XG-24F Dubai distinguishes itself from switches that claim stackability but involve the separate administration and troubleshooting of individual components. Offering genuine stacking capability, it enables you to seamlessly configure, manage, and troubleshoot multiple physical switches as a single integrated device, simplifying the process of network expansion. The integrated true stack functionality unifies the data and control plane, along with a management plane, fostering flexibility, scalability, and user-friendly operations as the stack of units functions as a cohesive entity, encompassing all ports of the stack members.
Moreover, the Cisco SG550XG-24F Dubai Switch provides the advanced feature set demanded by growing businesses and necessary for high-bandwidth applications and technologies.
Features
Affordable 10 Gigabit Ethernet
10 Gigabit Ethernet delivers 10 times the performance to your network to promote higher productivity and business efficiency. The Cisco SG550XG-24F Dubai breaks the barrier of 10 Gigabit Ethernet adoptions with exceptional affordability.
Unmatched reliability and resiliency
The Cisco SG550XG-24F Dubai offers true stacking, built-in fan redundancy, a redundant power supply connector, and high-availability protocols. Keep your network running so your business never slows down.
Advanced features
The Cisco SG550XG-24F Dubai includes capabilities and management options you need to support applications today and in the future, such as strong security, advanced QoS, comprehensive IPv6 support, and Layer 3 dynamic routing.
Power over Ethernet
The Power over Ethernet Plus (PoE+) standard provides up to 30 watts of power per port. The Cisco SG550XG-24F Dubai also support 60W PoE on selected ports to power compact switches and high-power wireless access points.
Energy efficiency
Cisco SG550XG-24F Dubai packs a variety of energy-saving features, including energy-detect mode, cable-length detection, and Energy-Efficient Ethernet, provide an eco-friendly and cost-effective network solution without compromising performance.
Specifications
| Cable | |
| Connectivity Details Type | Serial cable |
| Included Qty | 1 |
| Capacity | |
| Type | VLANs supported |
| Value | 4094 |
| Type | IPv4 routes (static) |
| Value | 8000 |
| Type | IPv6 routes (static) |
| Value | 4000 |
| Type | ACL rules |
| Value | 2000 |
| Type | QoS hardware queues |
| Type | 8 |
| Dimensions & Weight | |
| Depth | 13.8 in |
| Height | 1.7 in |
| Weight | 9.17 lbs |
| Width | 17.3 in |
| Environmental Parameters | |
| Humidity Range Operating | 10 – 90% (non-condensing) |
| Humidity Range Storage | 10 – 90% (non-condensing) |
| Max Operating Temperature | 122 °F |
| Max Storage Temperature | 158 °F |
| Min Operating Temperature | 32 °F |
| Min Storage Temperature | -4 °F |
| Flash Memory | |
| Installed Size | 256 MB |
| Header | |
| Brand | Cisco |
| Compatibility | PC |
| Product Line | Cisco Small Business |
| Interface Provided | |
| Connector Type | RJ-45 |
| Type | (2) 10GBase-T
(24) SFP+ 10GBase-X Type A USB |
| Miscellaneous | |
| Authentication Method | RADIUS , Secure Shell (SSH) , TACACS+ |
| Color Category | Black |
| Compliant Standards | CSA 22.2 , FCC Part 15 A , UL 60950 |
| Encryption Algorithm | MD5 , SSL |
| MTBF | 642,449.21 hours |
| Networking | |
| Advanced Switching | Layer 3 |
| Compliant Standards | IEEE 802.1ab (LLDP) , IEEE 802.1D , IEEE 802.1p , IEEE 802.1Q , IEEE 802.1s , IEEE 802.1w , IEEE 802.1x , IEEE 802.3 , IEEE 802.3ab , IEEE 802.3ad (LACP) , IEEE 802.3az , IEEE 802.3u , IEEE 802.3x , IEEE 802.3z |
| Connectivity Technology | Wired |
| Features | 16MB packet buffer , 802.1x authentication , Access Control List (ACL) support , ARP support , BOOTP support , Bridge protocol data unit (BPDU) , Broadcast Storm Control , Denial of Service (DoS) , DHCP client , DHCP relay , DHCP server , DHCP snooping , DHCP support , DiffServ Code Point (DSCP) support , DiffServ support , DoS attack prevention , Dynamic ARP Inspection (DAI) , Energy Efficient Ethernet , Flow control , Generic Attribute Registration Protocol (GARP) , Generic VLAN Registration Protocol (GVRP) , IGMP snooping , Internet Control Message Protocol (ICMP) , IP source guard , IP-MAC binding , Link Aggregation Control Protocol (LACP) , LLDP support , Management Information Base (MIB) , Multicast Storm Control , Multicast VLAN Registration (MVR) , Multiple Spanning Tree Protocol (MSTP) support , Port Security , Quality of Service (QoS) , Rapid Spanning Tree Protocol (RSTP) support , Spanning Tree Protocol (STP) support , STP Root Guard , Syslog support , Type of Service (ToS) , Uni-Directional Link Detection (UDLD) , Unicast Storm Control , Virtual Route Redundancy Protocol (VRRP) support , Weighted Round Robin (WRR) queuing |
| Form Factor | Desktop , Rack-mountable |
| Jumbo Frame Support | 9000 bytes |
| MAC Address Table Size | 64K entries |
| Manageable | Yes |
| Max Units In A Stack | 8 |
| Ports Qty | 24 |
| Power Over Ethernet (PoE) | No |
| Remote Management Protocol | CLI , HTTP , HTTPS , RMON , SCP , SNMP 1 , SNMP 2c , SNMP 3 , SSH , TFTP |
| Routing Protocol | CIDR , IGMP , IGMPv2 , IGMPv3 , MLD , MLDv2 , RIP , Static IPv4 routing , Static IPv6 routing , VRRP |
| Stackable | Stackable |
| Status Indicators | Fan , Link/activity , Port transmission speed , RPS (Redundant Power Supply) , System |
| Subcategory | Network hubs and switches |
| Subtype | 10 Gigabit Ethernet |
| Type | Switch |
| Power Device | |
| Features | Redundant Power System (RPS) connector |
| Frequency Required | 50/60 Hz |
| Nominal Voltage | AC 120/230 V |
| Power Consumption Operational | 77.5 Watt |
| Type | Internal power supply |
| RAM Size | 512 MB |
