Description

Cisco WAP131 Dubai

The Cisco WAP131 Dubai serves as a Wireless-N Dual Radio Access Point, tailored to offer a seamless and cost-efficient solution for extending secure, high-performance mobile networking to both employees and guests, ensuring connectivity across the office premises. It facilitates the connection of numerous employees and can adapt to accommodate additional users and evolving business demands.

Utilizing concurrent dual-band radios, the Cisco WAP131 Dubai ensures enhanced coverage and increased user capacity. Moreover, its Gigabit Ethernet port enables the AP to be powered by a PoE switch, effectively reducing cabling and wiring expenses. Intelligent quality-of-service (QoS) features prioritize bandwidth-sensitive traffic, catering to voice over-IP (VoIP) and video applications, thereby optimizing network performance.

Cisco Wi-Fi Dubai boasts a user-friendly setup process, facilitated by an intuitive wizard-based configuration that allows for a quick start within minutes. Its sleek desktop design, complemented by an integrated stand, provides the flexibility to position the access point vertically or horizontally on your desk.

To fortify reliability and protect sensitive business data, the Cisco WAP131 Dubai Wireless-N Dual Radio Access Point supports both Wi-Fi Protected Access (WPA) Personal and Enterprise, ensuring that all wireless transmissions are encoded with robust encryption. Additionally, 802.1 X RADIUS authentications play a pivotal role in preventing unauthorized access, thereby enhancing network security.

Features

Cisco WAP131 Dubai offers concurrent dual-band radio support for up to 300 Mbps per radio to maximize capacity and coverage.
Cisco Wi-Fi Dubai is equipped with a single Gigabit Ethernet LAN interface which enables a high-speed uplink to the wired network.
Cisco WAP131 Dubai offers robust security, including WPA2, 802.1X with RADIUS secure authentication, and rogue-access-point detection, helps protect sensitive business information.
Simple installation and intuitive web-based configuration and wizard enable fast, simple deployment and setup in minutes.
Cisco Wi-Fi Dubai boasts of a simple, desktop design with integrated stand, for easy access and placement.
Intelligent QoS prioritizes network traffic to help keep critical network applications running at top performance.
Cisco WAP131 Dubai has power-saving sleep mode and port control features which help maximize energy efficiency.
Workgroup Bridge mode lets you expand your network by wirelessly connecting to a second Ethernet network.
Cisco WAP131 Dubai has built-in support for IPv6 lets you deploy future networking applications and operating systems without costly upgrades.
Limited lifetime hardware warranty provides peace of mind.

Specifications

Specifications	Description
Standards	IEEE 802.11n, 802.11g, 802.11b, 802.3af, 802.3u, 802.1X (security authentication), 802.1Q (VLAN), 802.1D (Spanning Tree), 802.11i (WPA2 security), 802.11e (wireless QoS), IPv4 (RFC 791), IPv6 (RFC 2460)
Cabling type	Category 5e or better
Antennas	Internal antennas optimized for desktop installation with vertical orientation
LED indicators	Power, WLAN, LAN
Operating system	Linux
Physical Interfaces
Ports	10/100/1000 Ethernet, with support for 802.3af/at PoE, Power Port for AC adapter
Power Supply	External 12V 1.5A DC power jack (Energy Star 2.0 compliant with Efficiency Level 5) and 802.3af/at PoE
Buttons	Reset button, Power (on/off), Push button
Lock slot	Slot for Kensington lock
LEDs	Power, Wireless, Ethernet
Physical Specifications
Physical dimensions (W x D x H)	6.693 x 6.693x 1.413 in. (170 x 170 x 35.9 mm)
Weight	0.89 lb (0.40kg)
Network Capabilities
VLAN support	Yes
Number of VLANs	1 management VLAN plus 8 VLANs for SSIDs
802.1X supplicant	Yes
SSID-to-VLAN mapping	Yes
Auto channel selection	Yes
Spanning tree	Yes
Load balancing	Yes
IPv6	Yes IPv6 host support IPv6 RADIUS, syslog, Network Time Protocol (NTP), etc.
Layer 2	802.1Q-based VLANS, 8 active VLANS plus 1 management VLAN
Security
WPA and WPA2	Yes, including Enterprise authentication
Access control	Yes, management access control list (ACL) plus MAC ACL
Secure management	HTTPS
SSID broadcast	Yes
Rogue-access-point detection	No
Mounting and Physical Security
Mounting options	Desktop only
Physical security lock	Kensington lock slot
Quality of Service
Quality of service (QoS)	Wi-Fi Multimedia and Traffic Specification (WMM TSPEC), Client QoS
Performance
Wireless throughput	Up to 300-Mbps data rate (real-world throughput will vary)
Recommended user support	Up to 32 connective users, 16 active users per radio
Configuration
Web user interface	Built-in web user interface for easy browser-based configuration (HTTP/HTTPS)
Management
Management protocols	Web browser, Simple Network Management Protocol (SNMP) v3, Bonjour
Remote management	Yes
Event logging	Local, remote syslog, email alerts
Network diagnostics	Logging and packet capture
Web firmware upgrade	Firmware upgradable through web browser, imported/exported configuration file
Dynamic Host Configuration Protocol (DHCP)	DHCP client
IPv6 host	Yes
HTTP redirect	No
Wireless
Frequency	Dual concurrent radios (2.4 and 5 GHz)
Radio and modulation type	Dual radio, orthogonal frequency division multiplexing (OFDM)
WLAN	802.11n 2×2 multiple-input multiple-output (MIMO) with 2 spatial streams 20, and 40 MHz for 802.11n PHY data rate up to 600 Mbps
Data rates supported	802.11a/b/g : 54, 48, 36, 24, 18, 12, 9, 6, 11, 5.5, 2, and 1 Mbps 802.11n : 6.5 to 300 Mbps 20-MHz bandwidth : MCS 0-15 for supported data rates 40-MHz bandwidth : MCS 0-15 for supported data rates
Frequency Band and 20-MHz Operating Channels	A Regulatory Domain : 2.412 to 2.462 GHz; 11 channels 5.180 to 5.240 GHz; 4 channels 5.745 to 5.825 GHz; 5 channels	E Regulatory Domain: 2.412 to 2.472 GHz; 13 channels 5.180 to 5.240 GHz; 4 channels C Regulatory Domain: 2.412 to 2.462 GHz; 11 channels 5.745 to 5.805 GHz; 4 channels
Maximum Number of Non-overlapping Channels	2.4 GHz 802.11b/g 20 MHz : 3 802.11n 20 MHz : 3	5 GHz 802.11a 20 MHz : 9 802.11n 20 MHz : 9 40 MHz : 4
Wireless isolation	Wireless isolation between clients
External antennas	None
Internal antennas	Internal Fixed PiFA Antenna
Antenna gain in dBi	Maximum antenna gain of 3.4 dBi on 2.4 GHz Maximum antenna gain of 4.5 dBi on 5 GHz
Wireless distribution system (WDS)	Yes
802.11i	Yes
Multiple SSIDs	8
Wireless VLAN map	Yes
WLAN security	Yes
Wi-Fi Multimedia (WMM)	Yes, with unscheduled automatic power save
Operating Modes
Access point	Access Point mode, WDS Bridging, Workgroup Bridge mode
Environmental
Power options	IEEE 802.3af/at Ethernet switch Cisco Power Injector – SB-PWR-INJ2-xx AC Adapter – included 12v1.5A PoE Peak power : 7.42W
Compliance	Safety: UL 60950-1 CAN/CSA-C22.2 No. 60950-1 IEC 60950-1 EN 60950-1 Radio approvals: FCC Part 15.247, 15.407 RSS-210 (Canada) EN 300.328, EN 301.893 (Europe) AS/NZS 4268.2003 (Australia and New Zealand) EMI and susceptibility (Class B): FCC Part 15.107 and 15.109 ICES-003 (Canada) EN 301.489-1 and -17 (Europe)
Operating temperature	0° to 40°C (32° to 104°F)
Storage temperature	-20° to 70°C (-4° to 158°F)
Operating humidity	10% to 85% noncondensing
Storage humidity	5% to 90% noncondensing
System memory	128-MB RAM 128-MB Flash
Package Contents
Cisco WAP131 Wireless-N Dual Radio Access Point AC Power Adapter User guide on CD-ROM Quick-start guide Ethernet network cable
Minimum Requirements
Switch or router with PoE support, PoE injector, or AC Power Adapter Web-based configuration : Java-enabled web browser
Warranty
Access point	Limited lifetime
