The Fanvil PA2 Dubai SIP Paging Gateway is a powerful and cost-effective solution for businesses looking to implement a paging and intercom system. It supports SIP 2.0 and is compatible with most SIP-based PBX systems, including Asterisk, FreePBX, and 3CX.

Category:

Description

Fanvil PA2 Dubai

The Fanvil PA2 Dubai  SIP Paging Gateway is a versatile and cost-effective solution for businesses that need to implement a paging and intercom system. This device provides a reliable, high-quality audio experience that is ideal for use in a variety of environments, including warehouses, factories, schools, hospitals, and more.

One of the key features of the Fanvil PA2 Dubai SIP Paging Gateway is its built-in amplifier, which provides up to 10 watts of output power. This ensures that paging messages are loud and clear, even in noisy environments. The device also supports multiple audio codecs, including G.711, G.722, and G.729, ensuring that audio quality is always of the highest standard.

The Fanvil PA2 Dubai SIP Paging Gateway can be easily integrated with a variety of SIP-based PBX systems, including Asterisk, FreePBX, and 3CX. It supports SIP 2.0 and can be configured using a user-friendly web-based interface, making it easy to manage and monitor the system remotely.

The Fanvil PA2 Dubai SIP Paging Gateway has a variety of advanced features, including support for multiple multicast groups, automatic gain control, and noise reduction. These features ensure that paging messages are clear and easy to understand, even in noisy environments.

In addition to its powerful audio capabilities, the Fanvil PA2 SIP Paging Gateway has a durable design that can withstand harsh environmental conditions. It has an aluminum casing and is designed to be both dustproof and waterproof, making it ideal for use in industrial environments.

The Fanvil PA2 Dubai SIP Paging Gateway can also be used as a standalone device or integrated with an existing paging system. It can support up to 50 SIP accounts, allowing for multiple paging zones to be created throughout a facility. The device also supports two-way communication, allowing for intercom functionality between the gateway and IP phones.

Overall, the Fanvil PA2 SIP Paging Gateway is a reliable, cost-effective solution for businesses that need to implement a paging and intercom system. Its powerful audio capabilities, advanced features, and durable design make it an ideal choice for a variety of environments. Additionally, its easy integration with SIP-based PBX systems and user-friendly web-based interface make it easy to manage and monitor the system remotely.

Fanvil PA2 Specifications

Intercom

  • Two SIP lines, supporting SIP 2.0 (RFC3261) and related RFC
  • Supports two lines RTSP
  • Voice broadcast IP address
  • Button or remote volume adjustment
  • Switch signal input and output
  • Talkback recording output
  • Handsfree talking
  • Default auto answer
  • Dynamic multicast function
  • Supports DC or PoE power supply
  • Support for Function key interface
  • Support monophonic active speakers
  • Network time synchronization
  • Action URL / Active URI remote control

Audio

  • Narrowband speech coding: G.711a / u,G.723.1, G.726-32K, G.729AB
  • Broadband speech coding: G.722
  • Duplex intercom with Acoustic Echo Canceller (AEC)
  • DTMF: In-band, out-of-band DTMF (RFC2833) / SIP Info

Networking/ Protocols

  • Supports PoE
  • Primary and secondary DNS servers are supported
  • Support VLAN
  • Supports SNTP client
  • Support L2TP / OpenVPN
  • Supports SRTP
  • Support for HTTP / HTTPS web pages
  • Support Qos: 802.1p / q, DSCP
  • Support MD5 authentication
  • Supports Web Filter
  • DHCP / Static / PPPoE
  • STUN

Physical Specifications

  • 2 RJ45 interface:
  • Yellow: WAN port 10 / 100M adaptive,
  • support PoE
  • PoE: (Class 3: 6.49 ~ 12.95W)
  • Black: LAN port (Only connected to the original camera)
  • Cable: Super five lines or better
  • 1 blue indicator (SIP status and network status)
  • 2 volume plus or minus key
  • 1 restore factory settings key
  • 1 recording output interface:3.5mm standard audio interface 15 Ohm impedance
  • 1 ground screw
  • 1 way passive speaker interface: Output power: 4Ω, PoE / 10W, 12V /10W,18V / 20W, 24V / 30W; related to supply
  • voltage.
  • Wire diameter: 18 AWG or larger diameter Interface: Pluggable terminal block
  • 1 headset speaker：
  • Housing material: aluminum alloy shell
  • Installation: Indoor installation
  • Operating temperature: -30 ~ 60 ℃
  • Storage temperature: -30 ~ 60 ℃
  • Relative humidity: 10% – 95%
  • Equipment size: 113x83x28mm
  • Packing size: 138x108x77mm
  • Equipment weight: 250g
