The Fanvil X301G Dubai is an IP phone designed for small businesses. It features a 128×48 pixel display, supports up to two SIP accounts, and is built with advanced security protocols like HTTPS, SRTP, and TLS.

Category:

Description

Fanvil X301g Dubai

The Fanvil X301g Dubai is an advanced IP phone designed for business environments where reliability, efficiency, and quality communication are key requirements. The phone is feature-rich, stylishly designed, and offers excellent performance that suits small to medium-sized businesses.

One of the standout features of the Fanvil X301g Dubai is its support for Gigabit Ethernet, which delivers faster data transfer rates and higher quality audio and voice transmission compared to other IP phones. This means that users can expect a smooth and lag-free communication experience. The phone also supports Power over Ethernet (PoE), allowing it to receive both power and data through a single Ethernet cable, making it easy to install and maintain.

The Fanvil X301g Dubai supports up to two SIP accounts, enabling users to make and receive calls simultaneously using a variety of features, such as call waiting, call forwarding, and three-way conferencing. The phone supports a range of audio codecs, including G.711a/u, G.722, G.723, G.726, and G.729, ensuring that audio quality is always clear and reliable.

The phone is equipped with advanced security features, such as Transport Layer Security (TLS) and Secure Real-time Transport Protocol (SRTP), which encrypt communication and ensure that data is kept secure and confidential. The phone also supports HTTPS and SRTP verification, providing further protection against unauthorized access and interception.

The Fanvil X301g Dubai comes with a range of additional features, including a full-duplex speakerphone, EHS wireless headset support, and a built-in 10/100/1000 Mbps Ethernet switch with dual Gigabit Ethernet ports. The phone also supports customization options such as personalized ringtones and wallpapers, as well as the ability to configure the phone’s LED lights and display settings.

In terms of design, the Fanvil X301g Dubai has a sleek and modern appearance, with a 2.8-inch color LCD display that is easy to navigate. The phone is constructed using high-quality materials and is designed to be durable and long-lasting.

Overall, the Fanvil X301g Dubai is an ideal solution for businesses looking for a high-quality, reliable IP phone with advanced security features and customization options. With its impressive range of features and reliable performance, the Fanvil X301g Dubai is an excellent investment for any business that values efficient and quality communication.

Fanvil X301g Specifications

Generic

  • 2 SIP Lines
  • HD Voice
  • PoE Enabled
  • Dot-matrix display screen
  • Handset / Hands-free / Headset mode
  • Desktop Stand / Wall mountable (optional)
  • Optional External Power Supply

Phone Functions

  • Local Phonebook (1000 entries)
  • Remote Phonebook (XML/LDAP, 1000 entries)
  • Call logs (In/Out/Missed, 600 entries)
  • Blocked List/Allowed List
  • Voice Message Waiting Indication (VMWI)
  • Programmable DSS/Soft keys
  • Network Time Synchronization
  • Support Plantronics wireless headset (Through Plantronics APD-80 EHS Cable)
  • Support Jabra wireless headset (Through Fanvil EHS20 EHS Cable)
  • Support Recording (Through Server)
  • Action URL / Active URI
  • uaCSTA

Call Functions

  • Call out / Answer / Reject
  • Mute / Unmute (Microphone)
  • Call Hold / Resume
  • Call Waiting
  • Intercom
  • Caller ID Display
  • Speed Dial
  • Anonymous Call (Hide Caller ID)
  • Call Forward(Always/Busy/No Answer)
  • Call Transfer (Attended/Unattended)
  • Call Parking/Pick-up (Depending on server)
  • Redial
  • Do-Not-Disturb
  • Auto-Answering
  • Voice Message (with server)
  • 6-way Conference
  • Hot Line
  • Hot desking

Audio

  • HD Voice Microphone/Speaker
  • Wideband ADC/DAC 16KHz Sampling
  • Narrowband Codec: G.711a/u, G.723.1,G.726,G.729A/B, iLBC
  • Wideband Codec: G.722, Opus
  • Full-duplex Acoustic Echo Canceller (AEC)
  • Voice Activity Detection (VAD) / Comfort Noise Generation (CNG)/ Background Noise Estimation (BNE) / Noise Reduction
  • (NR) /Automatic Gain Control (AGC)
  • Packet Loss Concealment (PLC)
  • Dynamic Adaptive Jitter Buffer
  • DTMF: In-band, Out-of-Band (RFC2833/ SIP INFO)
  • VQM voice quality monitoring

Network

  • Physical: 10/100/1000 Mbps Ethernet, dual bridged port for PC bypass
  • IP Mode: IPv4/IPv6
  • IP Configuration: Static IP / DHCP / PPPoE
  • Network Access Control: 802.1x
  • VPN: L2TP / OpenVPN
  • VLAN
  • LLDP
  • QoS
  • RTCP-XR (RFC3611), VQ-RTCPXR (RFC6035)

Protocols

  • SIP2.0 over UDP/TCP/TLS
  • RTP/RTCP/SRTP
  • STUN
  • DHCP
  • IPV6
  • LLDP
  • PPPoE
  • 802.1x
  • L2TP
  • OpenVPN
  • SNTP
  • FTP/TFTP
  • HTTP/HTTPS
  • TR-069
  • AES128 & AES256

Physical Specifications

  • LCD: 128×48 pixel graphical LCD with backlight
  • Keypad: 33 keys
  • Handset (RJ9) x1
  • Standard RJ9 Handset Wire x1
  • 1.5M CAT.5E Ethernet Cable x1
  • Desktop stand x1
  • Status Indicator Light x1 (Red)
  • RJ9 Port x2: Handset x1, Headset x1
  • RJ45 Port x2: Network x1, PC x1 (Bridged to Network)
  • Security Slot x1
  • DC Power Input: 5V/0.6A
  • Power Consumption(Adapter): 0.8~1.29W
  • Power Consumption(PoE): 1.25~1.86W
  • Working Temperature: 0~45℃
  • Working Humidity: 10~95%
  • Color: Black
  • N.W/CTN: 8.55kg
  • G.W/CTN: 9.26kg
  • Desktop Stand (45°): 169×201.1×177.4 mm
  • Desktop Stand (50°): 169×191.9×185.8 mm
  • Wall mountable: 169×120.1×213.7 mm
  • Gift Box Dimensions: 250x220x55mm
  • Outer CTN Dimensions: 460x300x270mm(10 PCS)
