Description

Fanvil X303 Dubai

The Fanvil X303 Dubai is a high-quality IP phone designed for business use. It is a mid-range phone that offers a range of advanced features and functions, making it an ideal choice for small to medium-sized businesses.

One of the key features of the Fanvil X303 Dubai is its large monochrome display. The display measures 128 x 64 pixels and offers excellent visibility in any lighting conditions. The user interface is simple and easy to navigate, with clearly labeled buttons and menus that make it easy to access the phone’s many functions and features.

The Fanvil X303 Dubai is highly programmable, with support for up to 12 programmable DSS keys. These keys can be programmed with a wide range of functions, including speed dialing, call transfer, and conference calling, among others. The phone also supports up to 5 virtual DSS keys, giving users even more options for customization.

In addition to its advanced programmability, the Fanvil X303 Dubai is also highly compatible with a wide range of VoIP protocols. The phone supports SIP 2.0, IPv6, and various codecs, including G.711a/u, G.723.1, G.726, G.729AB, and iLBC. This makes it an ideal choice for businesses that require interoperability with a variety of different VoIP systems.

Security is also a major priority for the Fanvil X303 Dubai. The phone includes advanced security features such as HTTPS, SRTP, and TLS encryption, which help to ensure the privacy and security of communications. It also includes a built-in VPN client, which allows users to securely connect to a company’s VPN network.

The Fanvil X303 Dubai is a highly versatile device, with a range of additional features that make it an excellent choice for business use. The phone includes a built-in headset port, which allows users to connect a headset for hands-free calling. It also features dual 10/100Mbps Ethernet ports, which support PoE and allow for high-speed data transfer.

The Fanvil X303 Dubai supports up to 2 SIP lines, making it a powerful and scalable solution for small to medium-sized businesses. It also includes advanced call management features such as call forwarding, call waiting, and call hold, as well as advanced audio features such as echo cancellation and noise reduction.

In summary, the Fanvil X303 Dubai is a high-quality and feature-rich IP phone that is ideally suited for small to medium-sized businesses. Its large monochrome display, advanced programmability, and compatibility with a wide range of VoIP protocols make it an excellent choice for businesses that require reliable and high-quality communication. Its advanced security features, built-in headset port, and dual Ethernet ports further enhance its versatility and functionality.

Fanvil X303 Specifications

Generic

• 4 SIP Lines
• HD Voice
• PoE Enabled (only X303P)
• 2.4-inch color screen
• Handset / Hands-free / Headset mode
• Desktop Stand / Wall mountable (optional)
• Optional External Power Supply

Phone Functions

• Local Phonebook (1000 entries)
• Remote Phonebook (XML/LDAP, 1000 entries)
• Call logs (In/Out/Missed, 600 entries)
• Blocked List/Allowed List
• Screen saver
• Voice Message Waiting Indication (VMWI)
• Programmable DSS/Soft keys
• Network Time Synchronization
• Support Plantronics wireless headset (Through Plantronics APD-80 EHS Cable)
• Support Jabra wireless headset (Through Fanvil EHS20 EHS Cable)
• Support Recording (Through Server)
• Action URL / Active URI
• uaCSTA

Call Functions

• Call out / Answer / Reject
• Mute / Unmute (Microphone)
• Call Hold / Resume
• Call Waiting
• Intercom
• Caller ID Display
• Speed Dial
• Anonymous Call (Hide Caller ID)
• Call Forward (Always/Busy/No Answer)
• Call Transfer (Attended/Unattended)
• Call Parking/Pick-up (Depending on server)
• Redial
• Do-Not-Disturb
• Auto-Answering
• Voice Message (On server)
• 6-way Conference
• Hot Line
• Hot desking

Audio

• HD Voice Microphone/Speaker (Handset/Hands-free, 0 ~ 7KHz Frequency Response)
• Wideband ADC/DAC 16KHz Sampling
• Narrowband Codec: G.711a/u,G.723.1,G.726, G.729A/B, iLBC
• Wideband Codec: G.722, Opus
• Full-duplex Acoustic Echo Canceller (AEC)
• Voice Activity Detection (VAD) / Comfort Noise Generation (CNG)/ Background Noise Estimation (BNE) / Noise Reduction (NR) /Automatic Gain Control (AGC)
• Packet Loss Concealment (PLC)
• Dynamic Adaptive Jitter Buffer
• DTMF: In-band, Out-of-Band (RFC2833/ SIP INFO)
• VQM voice quality monitoring

Network

• Physical: 10/100 Mbps Ethernet, dual bridged port for PC bypass
• IP Mode:IPv4/IPv6
• IP Configuration: Static IP / DHCP / PPPoE
• Network Access Control: 802.1x
• VPN: L2TP / OpenVPN
• VLAN
• LLDP
• QoS
• RTCP-XR (RFC3611), VQ-RTCPXR (RFC6035)

Protocols

• SIP2.0 over UDP/TCP/TLS
• RTP/RTCP/SRTP
• STUN
• DHCP
• IPv6
• LLDP
• PPPoE
• 802.1x
• L2TP
• OpenVPN
• SNTP
• FTP/TFTP
• HTTP/HTTPS
• TR-069
• AES128 & AES256

Physical Specifications

• LCD: 2.4-inch (320×240) Color Screen
• Keypad: 36 keys
• Handset (RJ9) x1
• Standard RJ9 Handset Wire x1
• 1.5M CAT.5E Ethernet Cable x1
• Desktop Stand x1
• Status Indicator Light x1 (Red)
• RJ9 Port x2: Handset x1, Headset x1
• RJ45 Port x2: Network x1, PC x1 (Bridged to Network)
• Security Slot x1
• DC Power Input: DC5V / 0.6A
• Power Consumption(Adapter): 0.84~1.43W
• Power Consumption(PoE): 1.32~2.09W
• Working Temperature: 0~45℃
• Working Humidity: 10~95%
• Color: Black
• N.W/CTN: 8.95kg(X303), 8.5kg(X303P)
• G.W/CTN: 9.66kg(X303), 9.21kg(X303P)
•  Desktop Stand (45°): 169×201.1×177.4 mm
•  Desktop Stand (50°): 169×191.9×185.8 mm
•  Wall mountable: 169×120.1×213.7 mm
• Gift Box Dimensions: 250x220x55mm
• Outer CTN Dimensions: 460x300x270mm(10 PCS)
