Description

Fanvil X5U Dubai

The Fanvil X5U Dubai is an IP phone designed for business use. It offers several advanced features that make it highly efficient and versatile, including a 3.5-inch color screen, support for up to 16 SIP lines, built-in Bluetooth and Wi-Fi connectivity, advanced audio technologies, and programmable keys.

The 3.5-inch color screen displays important information such as caller ID, call duration, and contacts. It is easy to navigate, and the icons are clear and intuitive. The device supports up to 16 SIP lines, which allows users to manage multiple phone numbers and call plans on a single device.

The Fanvil X5U Dubai features advanced audio technologies such as noise reduction and echo cancellation, ensuring high-quality audio communication. It also has a full-duplex speakerphone and supports HD audio, making it easy for users to communicate clearly and effectively. The device has a built-in microphone and a 3.5mm audio jack, enabling users to connect external speakers or headphones.

The Fanvil X5U Dubai supports PoE (Power over Ethernet), which means that it can receive power and data over a single Ethernet cable. This feature eliminates the need for additional power cables, making installation easy and cost-effective. The device also supports VLAN (Virtual Local Area Network) and QoS (Quality of Service), ensuring that network traffic is prioritized and managed efficiently.

The Fanvil X5U Dubai has built-in Bluetooth and Wi-Fi connectivity, enabling users to connect to wireless networks and devices such as headsets, smartphones, and tablets. It also supports EHS (Electronic Hook Switch) and various types of headsets, including wireless, wired, and Bluetooth.

With a range of programmable keys, the Fanvil X5U Dubai is highly customizable and configurable. It supports various features, such as LDAP, XML phonebook, and multiple languages, making it suitable for use in various international settings. The device has 8 programmable keys and can support up to 30 DSS keys, allowing users to customize their phone according to their needs and preferences.

The Fanvil X5U Dubai is also designed with security in mind. It supports various security protocols, such as TLS, SRTP, HTTPS, and VLAN, ensuring that communications over the device are secure and protected against unauthorized access.

In conclusion, the Fanvil X5U Dubai is an advanced IP phone that is highly suitable for business use. Its 3.5-inch color screen, support for up to 16 SIP lines, advanced audio technologies, and built-in Bluetooth and Wi-Fi connectivity make it highly efficient and versatile. Its customizable features, PoE support, and advanced security features make it easy to use and highly adaptable to different settings. Whether for personal or professional use, the Fanvil X5U Dubai is an excellent choice for anyone looking for a reliable, high-performance IP phone.

Fanvil X5U Specification

Generic

• 16 SIP Lines
• HD Voice
• PoE Enabled
• 2 LCDs (Main + DSS)
• Handset / Hands-free / Headset mode
• Intelligent DSS Keys
• Desktop Stand / Wall-mounted (need an additional wall hanging parts)
• Optional External Power Supply

Phone Functions

• Local Phonebook (2000 entries)
• Remote Phonebook (XML/LDAP, 2000 entries)
• Call logs (In/Out/Missed, 1000 entries)
• Black/White List Call Filter
• Screen saver
• Voice Message Waiting Indication (VMWI)
• Programmable DSS/Soft keys
• Network Time Synchronization
• Built-in Bluetooth 2.1: Support Bluetooth headset
• Support Wi-Fi Dongle
• Support Plantronics wireless headset (Through Plantronics APD-80 EHS Cable)
• Support Jabra wireless headset (Through Fanvil EHS20 EHS Cable)
• Support Recording (Through Flash Drive or Server)
• Action URL / Active URI
• uaCSTA

Call Functions

• Call out / Answer / Reject
• Mute / Unmute (Microphone)
• Call Hold / Resume
• Call Waiting
• Intercom
• Caller ID Display
• Speed Dial
• Anonymous Call (Hide Caller ID)
• Call Forward (Always/Busy/No Answer)
• Call Transfer (Attended/Unattended)
• Call Parking/Pick-up (Depending on server)
• Redial
• Do-Not-Disturb
• Auto-Answering
• Voice Message (With server)
• 3-way Conference
• Hot Line
• Hot desking

Audio

• HD Voice Microphone/Speaker (Handset/Hands-free, 0 ~ 7KHz Frequency Response)
• HAC handset
• Wideband ADC/DAC 16KHz Sampling
• Narrowband Codec: G.711a/u, G.723.1, G.726-32K, G.729AB,AMR, iLBC
• Wideband Codec: G.722, AMR-WB, Opus
• Full-duplex Acoustic Echo Canceller (AEC)
• Voice Activity Detection (VAD) / Comfort Noise Generation (CNG)/ Background Noise Estimation (BNE) / Noise Reduction (NR)
• Packet Loss Concealment (PLC)
• Dynamic Adaptive Jitter Buffer
• DTMF: In-band, Out-of-Band – DTMF-Relay (RFC2833) / SIP INFO

Network

• Physical: 10/100/1000 Mbps Ethernet, dual bridged port for PC bypass
• IP Mode:IPv4/IPv6/IPv4&IPv6
• IP Configuration: Static IP/ DHCP / PPPoE
• Network Access Control: 802.1x
• VPN: L2TP / OpenVPN
• VLAN
• LLDP
• QoS
• RTCP-XR (RFC3611), VQ-RTCPXR (RFC6035)

Protocols

• SIP2.0 over UDP/TCP/TLS
• RTP/RTCP/SRTP
• STUN
• DHCP
• IPv6
• LLDP
• PPPoE
• 802.1x
• L2TP
• OpenVPN
• SNTP
• FTP/TFTP
• HTTP/HTTPS
• TR-069

Physical Specifications

• Main LCD x1: 3.5-inch (480×320) Color Screen
• DSS Key-mapping LCD x1: 2.4-inch (240×320) Color Screen
• Keypad: 42 keys
• Standard RJ9 Handset Wire x1
• 1.5M CAT5 Ethernet Cable x1
• Back Rack x1
• Status indicator light x1 (Red)
• RJ9 Port x2: Handset x1, Headset x1
• RJ45 Port x2: Network x1, PC x1 (Bridged to Network)
• USB2.0 Port x1: Standard A, Connect with Wi-Fi USB dongle or Flash Driver
• Safety Keyhole x1
• DC Power Input: 5V/2A
• Power Consumption (PoE): 1.7W~10.46W
• Power Consumption (Adapter): 1.38W~9.13W
• Working Temperature: 0~45℃
• Working Humidity: 10~95%
• Color: Black
• Gift Box Dimensions: 315x228x84 mm
• Outer CTN Dimensions: 476x440x335 mm (10 PCS)
