Grandstream GWN7660 Dubai

Grandstream GWN7660 Dubai

The Grandstream GWN7660 Dubai is an outdoor wireless access point designed for businesses and organizations that require reliable and secure Wi-Fi connectivity in outdoor environments. It features high-performance dual-band 802.11ac Wi-Fi with speeds of up to 1.3 Gbps.

Category:

Description

Grandstream GWN7660 Dubai

The Grandstream GWN7660 Dubai is a high-performance outdoor wireless access point that is ideal for businesses and organizations that require reliable and secure Wi-Fi connectivity in outdoor environments. With dual-band 802.11ac Wi-Fi, the Grandstream GWN7660 Dubai delivers speeds of up to 1.3 Gbps, making it ideal for high-density outdoor environments such as stadiums, campuses, and outdoor events.

One of the key features of the Grandstream GWN7660 Dubai is its rugged weatherproof design, which makes it resistant to extreme outdoor conditions. The device is IP66 rated, which means it is protected against dust, water, and other environmental hazards. This makes it an ideal solution for businesses that need to provide Wi-Fi connectivity in outdoor settings.

The Grandstream GWN7660 Dubai also includes advanced security features, such as WPA3 encryption and built-in firewall, ensuring that network resources and data are secure and protected from potential threats. The device also includes support for VLAN tagging, allowing businesses to segregate their network traffic and ensure that critical data is kept separate from other traffic.

In addition to its advanced security features, the GWN7660 also includes advanced QoS and bandwidth control features, allowing businesses to prioritize network traffic and optimize their network performance for different applications and services. The device also supports seamless roaming, allowing users to move throughout the outdoor area without experiencing any interruption in their wireless connection.

The GWN7660 is easy to install and manage, with a user-friendly web interface that simplifies the configuration process. The device can be powered through PoE (Power over Ethernet), reducing the need for additional power outlets and making installation more flexible.

The GWN7660 also includes advanced network management features, such as remote provisioning and monitoring, allowing IT administrators to manage and monitor the device remotely. This feature helps to ensure that the device is always up-to-date and operating at optimal performance.

Overall, the Grandstream GWN7660 is an ideal outdoor wireless access point for businesses and organizations that require reliable and secure Wi-Fi connectivity in outdoor environments. With its advanced features, high-performance capabilities, and rugged weatherproof design, the GWN7660 is a cost-effective and reliable solution for businesses looking to enhance their Wi-Fi capabilities in outdoor settings.

Grandstream GWN7660 Specifications

  • Wi-Fi Standards IEEE 802.11 a/b/g/n/ac/ax
  • Antennas 2 dual band internal antennas
    • 2.4GHz, gain 3dBi / 5 GHz, gain 4dBi
  • Wi-Fi Data Rates
  • 5G:
    • IEEE 802.11ax: 7.3 Mbps to 1201 Mbps;
    • IEEE 802.11ac: 6.5 Mbps to 867 Mbps;
    • IEEE 802.11n: 6.5Mbps to 300Mbps;
    • IEEE 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
  • 2.4G:
    • IEEE 802.11ax: 7.3 Mbps to 573.5 Mbps;
    • IEEE 802.11n: 6.5Mbps to 300Mbps;
    • IEEE 802.11b: 1, 2, 5.5, 11 Mbps;
    • IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
  • Frequency Bands 2.4GHz radio: 2400-2483.5MHz  5GHz radio: 5150-5850MHz
  • Channel Bandwidth 2.4G: 20 and 40 MHz  5G: 20,40 and 80 MHz
  • Wi-Fi and System Security
  • WEP, WPA/WPA2-PSK, WPA/WPA2 Enterprise (TKIP/AES); WPA3, anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate and random default password per device
  • MIMO 2×2:2 2.4GHz   2×2:2 5GHz
  • Coverage Range Up to 175 meters
  • Maximum TX Power
    • 5G: 22dBm
    • 2.4G: 24dBm
  • Receiver Sensitivity
  • 2.4G
    • 802.11b: -96dBm@1Mbps, -88dBm@11Mbps;
    • 802.11g: -93dBm @6Mbps, -75dBm@54Mbps;
    • 802.11n 20MHz: -73dBm @MCS7; 802.11n 40MHz: -70dBm @MCS7;
    • 802.11ax 20MHz: -60dBm @MCS11; 802.11ax 40MHz: -58dBm @MCS11;
  • 5G
    • 802.11a: -92dBm @6Mbps, -74dBm @54Mbps;
    • 802.11n 20MHz: -73dBm @MCS7; 802.11n 40MHz: -70dBm @MCS7;
    • 802.11ac 20MHz: -67dBm@MCS8; 802.11ac: 40MHz: -63dBm @MCS9; 802.11ac 80MHz: -59dBm @MCS9 ;
    • 802.11ax 20MHz: -60dBm @MCS11; 802.11ax 40MHz: -58dBm @MCS11;802.11ax 80MHz: -56dBm @MCS11
  • SSIDs 32 SSIDs total, 16 per radio (2.4ghz and 5 ghz)
  • Concurrent Clients 500+
  • Network Interfaces 2x autosensing 10/100/1000 Base-T Ethernet Ports
  • Auxiliary Ports 1x Reset Pinhole, 1x Kensington lock
  • Mounting Indoor wall mount or ceiling mount, kits included
  • LEDs 3 tri-color LEDs for device tracking and status indication
  • Network Protocols IPv4, IPv6, 802.1Q, 802.1p, 802.1x, 802.11e/WMM
  • QoS 802.11e/WMM, VLAN, TOS
  • Network Management
    • Embedded controller can manage up to 50 local GWN APs
    • GWN.Cloud offers a free cloud management platform for unlimited GWN APs
    • GWN Manager offers premise-based software controller for up to 3,000 GWN APs
  • Power and Green Energy Efficiency PoE 802.3af/ 802.3at; Maximum Power Consumption: 9W
  • Environmental
    • Operation: 0°C to 45°C
    • Storage: -10°C to 60°C
    • Humidity: 10% to 90% Non-condensing
  • Physical Unit Dimension: 180.4mmx180.4mmx40.8mm; Unit Weight: 443g Entire Package Dimension: 228.5x220x79mm; Entire Package Weight: 774g
  • Package Content GWN7660 802.11ax Wireless AP, Mounting Kits, Quick Start Guide
  • Compliance FCC, CE, RCM, IC
