| Protocols / Standards |
SIP RFC3261, TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP/RARP, ICMP, DNS (A record, SRV, NAPTR), DHCP, PPPoE, , TFTP, NTP, STUN, SIMPLE, TR-069, 802.1x, IPv6 |
| Network Interfaces |
Dual switched 10/100Mbps ports, integrated PoE (GXP1165 only) |
| Graphic Display |
128×40 graphical LCD display |
| Voice Codec |
Support for G.723.1, G.729A/B, G.711µ/a, G.726-32, G.722 (wide-band), iLBC, in-band and out-of-band DTMF (in audio, RFC2833, SIP INFO) |
| Telephony Features |
Hold, transfer, forward, 3-way conference, downloadable phone book (XML, LDAP, up to 500 items), call waiting, call log (up to 200 records), off-hook auto dial, auto answer, click-to-dial, flexible dial plan, hot-desking, personalized music ringtones, server redundancy and fail-over |
| Sample Applications |
Skype, Google Hangouts, Microsoft Lync, Web browser, Adobe Flash, Facebook, Twitter, YouTube, news, weather, stock, Internet radio, Pandora, Last.fm, Yahoo Flickr, Photobucket, alarm clock, Google calendar, mobile phone data import/export via Bluetooth, etc. API/SDK available for advanced custom application development. |
| Headset Jack |
RJ9, supporting Electronic Hook Switch (EHS) with Plantronics headsets |
| Base Stand |
Yes, 1 angle position available |
| Wall Mountable |
Yes |
| QoS |
Layer 2 (802.1Q, 802.1p) and Layer 3 (ToS, DiffServ, MPLS) QoS |
| Security |
User and administrator level passwords, MD5 and MD5-sess based authentication, AES encrypted configuration file, SRTP, TLS, 802.1x media access control |
| Multi-Language |
English, German, Italian, French, Spanish, Portuguese, Russian, Croatian, simplified and traditional Chinese, Korean, Japanese, etc. |
| Upgrade / Provisioning |
Firmware upgrade via TFTP/HTTP/HTTPS, mass provisioning using TR-069 or AES encrypted XML configuration file |
| Power and Green Energy Efficiency |
Universal power adapter included: Input: 100-240VAC 50-60Hz; Output: +5VDC, 800mA Integrated Power-over-Ethernet (802.3af,GXP1165 only) Max power consumption 2.5W (universal power adapter) or 3W (PoE) |
