The Cisco Meraki MR42E Dubai includes an integrated Layer 7 packet inspection, classification, and control engine, enabling you to set QoS policies based on traffic type. Prioritize your mission critical applications, while setting limits on recreational traffic.

Category:

Description

Meraki MR42E Dubai

The Meraki MR42E Dubai is a cloud-managed access point that offers general-purpose Wi-Fi with external antenna connectors. It is a 802.11ac Wave 2 access point that is designed for use in various settings such as offices, schools, shops, and hotels. With its 3×3 MIMO 802.11ac Wave 2 technology, it provides high performance, security, and manageability. The Meraki MR42E Dubai can deliver a maximum frame rate of 1.9 Gbps with its concurrent 802.11ac Wave 2 and 802.11n 3×3:3 MIMO radios. It also has a dedicated third radio that ensures security and spectrum visibility through 24×7 WIDS/WIPS and automated RF optimization. Additionally, it features an integrated Bluetooth low energy (BLE) radio for Beacon functionality and BLE device scanning. One of the key features of the Meraki MR42E Dubai is its support for a variety of smart, auto-detectable external antennas. These antennas can provide focused, targeted coverage in challenging RF environments, as well as broader coverage in different settings including those with high ceilings. The antenna options include panel and panel downtilt omni-directionals, wide patch, and narrow patch. The combination of cloud management, 802.11ac Wave 2 technology, full-time RF environment scanning, and integrated Bluetooth technology ensures high throughput, reliability, and flexibility for demanding business applications like voice and high-definition streaming video. The Meraki MR42E Dubai is a reliable and future-proof solution for businesses in Dubai and beyond.

Meraki MR42E Specifications

Radios

  • 4 GHz 802.11b/g/n client access radio
  • 5 GHz 802.11a/n/ac client access radio
  • 4 GHz & 5 GHz dual-band WIDS/WIPS, spectrum analysis, & location analytics radio
  • 4 GHz Bluetooth radio with Bluetooth Low Energy
    (BLE) and Beacon support
  • Concurrent operation of all four radios
  • Max dual–radio aggregate frame rate 1.9 Gbit/s
  • Supported frequency bands (country-specific restrictions apply):
    412-2.484 GHz
    5.150-5.250 GHz (UNII-1)
    5.250-5.350 GHZ (UNII-2)
    5.470-5.600, 5.660-5.725 GHz (UNII-2e)
    5.725 -5.825 GHz (UNII-3)

Antenna

  • Integrated omni-directional antennas (5 dBi gain at 2.4 GHz, 5.5 dBi gain at 5 GHz)
  • Individual antenna elements for each radio

802.11ac Wave 2 and 802.11n Capabilities

  • 3 x 3 multiple input, multiple output (MIMO) with three spatial streams
  • SU-MIMO and MU-MIMO support
  • Maximal ratio combining (MRC) & beamforming
  • 20 and 40 MHz channels (802.11n), 20, 40, and 80 MHz channels (802.11ac)
  • Up to 256-QAM on both 2.4 GHz & 5 GHz
  • Packet aggregation

Power

  • Power over Ethernet : 37 – 57 V (802.3at required with functionality-restricted 802.3af mode supported)
  • Alternative 12 V DC input
  • Power consumption : 20W max (802.3at)
  • Power over Ethernet injector and DC adapter sold separately

LED Indicators

  • Multi color & multi function status indicator

Interfaces

  • 1x 10/100/1000Base-T Ethernet (RJ45)
  • 1x DC power connector (5.5 mm x 2.5 mm, center positive)

Mounting

  • All standard mounting hardware included
  • Desktop, ceiling, and wall mount capable
  • Ceiling tile rail (9/16, 15/16 or 1 ½” flush or recessed rails), assorted cable junction boxes
  • Bubble level on mounting cradle for accurate horizontal wall mounting

Physical Security

  • Two security screw options (included)
  • Kensington lock hard point
  • Concealed mount plate with anti-tamper cable bay

Environment

  • Operating temperature : 32 °F to 104 °F (0 °C to 40 °C)
  • Humidity : 5 to 95% non-condensing

Physical Dimensions

  • 0” x 6.1” x 1.5” (253.4 mm x 155.8 mm x 37.1 mm), not including deskmount feet or mount plate
  • Weight : 25 oz (0.7kg)

Mobility

  • PMK and OKC credential support for fast Layer 2 roaming
  • Distributed or centralized layer 3 roaming

Security

  • Integrated Layer 7 firewall with mobile device policy management
  • Real-time WIDS/WIPS with alerting and automatic rogue Access Point containment with Air Marshal
  • Flexible guest access with device isolation
  • VLAN tagging (802.1q) and tunneling with IPsec VPN
  • PCI compliance reporting
  • WEP, WPA, WPA2-PSK, WPA2-Enterprise with 802.1X
  • EAccess Point -TLS, EAccess Point -TTLS, EAccess Point -MSCHAccess Point v2, EAccess Point -SIM
  • TKIP and AES encryption
  • Enterprise Mobility Management (EMM) & Mobile Device Management (MDM) integration

Quality of Service

  • Advanced Power Save (U-Access Point SD)
  • WMM Access Categories with DSCP and 802.1p support
  • Layer 7 application traffic identification and shaping

Analytics

  • Embedded location analytics reporting and device tracking
  • Global L7 traffic analytics reporting per network, per device, per application
