Meraki MR53E Dubai

Meraki MR53E Dubai

The Meraki MR53E Nigeria is a cloud-managed 4×4:4 802.11ac Wave 2 access point with 160 MHz channels and MU-MIMO support. Designed for demanding next-generation deployments in busy offices, schools, hospitals, stadiums, factories, warehouses, and other venues.

Category:

Description

Meraki MR53E Dubai

The Meraki MR53E Dubai is a cloud-managed access point that supports 802.11ac Wave 2 technology with 160 MHz channels and MU-MIMO. It is designed to meet the demands of modern deployments in various locations such as offices, schools, hospitals, stadiums, factories, and warehouses. The Meraki MR53E Dubai offers high performance, enterprise-grade security, and easy management. With its concurrent 2.4 GHz and 5 GHz radios, the Meraki MR53E Dubai provides a maximum aggregate frame rate of 2.5 Gbps*. It also has a dedicated third radio for real-time WIDS/WIPS with automated RF optimization, and a fourth integrated radio for Bluetooth Low Energy (BLE) scanning and Beaconing. The Meraki MR53E Dubai supports a range of smart, auto-detectable external antennas that can provide targeted coverage in challenging RF environments or broader coverage in different settings, including those with high ceilings. These antennas include options like panel and panel down-tilt omni-directional, wide patch, and narrow patch. One of the key advantages of the Meraki MR53E Dubai is its cloud-based firmware management. The device automatically receives new features, bug fixes, and enhancements through seamless updates over the web. This eliminates the need for manual software downloads or concerns about missing security patches. Combining cloud management, top-notch hardware, multiple radios, and advanced software features, the Meraki MR53E Dubai is an excellent choice for demanding use cases, including high-density deployments and bandwidth-intensive applications like voice and high-definition video. Managing the Meraki MR53E Dubai is made easy through the intuitive Meraki dashboard, a browser-based interface that allows rapid deployment across multiple sites without the need for extensive training or certifications. Additionally, the access point is self-configuring and can be deployed at remote locations within minutes, even without on-site IT personnel. The Meraki cloud provides 24/7 monitoring and real-time alerts in case of network issues, while remote diagnostic tools enable quick troubleshooting to ensure hassle-free management of distributed networks.

Meraki MR53E Specifications

Radios

  • 4 GHz 802.11b/g/n/ac client access radio
  • 5 GHz 802.11a/n/ac Wave 2 client access radio
  • 4 GHz & 5 GHz dual-band WIDS/WIPS, spectrum analysis, and location analytics radio
  • 4 GHz Bluetoth Low Energy (BLE) radio with Beacon and BLE scanning support
    Concurrent operation of all three radios
  • Supported frequency bands (country-specific restrictions apply) :
    • 412-2.484 GHz
    • 150-5.250 GHz (UNII-1)
    • 250-5.350 GHz (UNII-2)
    • 470-5.600, 5.660-5.725 GHz (UNII-2e)
    • 1725-5.825 GHz (UNII-3)

Antenna

  • List of compatible antennas : MA-ANT-3-A5/B5/C5/D5/E5/F5
  • Individual antenna elements for each radio

802.11ac Wave 2 and 802.11n capabilities

  • 4 x 4 multiple input, multiple output (MIMO) with four spatial streams
  • SU-MIMO and MU-MIMO support
  • Maximal ratio combining (MRC) and beamforming
  • 20 and 40 MHz channels (802.11n), 20, 40, 80, and 160 MHz channels (802.11ac)
  • Up to 256-QAM on both 2.4 GHz & 5 GHz bands
  • Packet aggregation

Power

  • Power over Ethernet : 37-57 V
  • (802.3at required; functionality-restricted 802.3af mode supported)
  • Alternative : 12 V DC input
  • Power consumption : 20 W max (802.3at)
  • Power over Ethernet injector and DC adapter sold separately

Interfaces

  • 1x 100/1000/2.5G BASE-T Ethernet
  • 1x 10/100/1000 BASE-T Ethernet (RJ45)
  • 1x DC power connector (5.5 mm x 2.5 mm, center positive)
  • Six external RP-TNC antenna connectors

Mounting

  • All standard mounting hardware included
  • Desktop, ceiling, and wall mount capable
  • Ceiling tile rail (9/16, 15/16, or 1 1/2” flush or recessed rails), assorted cable junction boxes
  • Bubble level on mounting cradle for accurate horizontal wall mounting

Physical Security

  • Two security screw options included
  • Kensington lock hard point
  • Concealed mount plate with anti-tamper cable bay

Environment

  • Operating temperature : 32 °F to 104 °F (0 °C to 40 °C)
  • Humidity : 5% to 95%

Security

  • Integrated Layer 7 firewall with mobile device policy management
  • Real-time WIDS/WIPS with alerting and automatic rogue Access Point containment with Air Marshal
  • Flexible guest access with device isolation
  • VLAN tagging (802.1Q) and tunneling with IPSec VPN
  • PCI compliance reporting
  • WEP, WPA, WPA2-PSK, WPA2-Enterprise with 802.1X
  • EAccess Point-TLS, EAccess Point-TTLS, EAccess Point-MSCHAccess Pointv2, EAccess Point-SIM
  • TKIP and AES encryption
  • Enterprise Mobility Management (EMM) & Mobile Device Management (MDM) integration
  • Cisco ISE integration for guest access and BYOD posturing

Physical Dimensions

  • 59” x 6.3” x 1.06” (269 mm x 160 mm x 27 mm), not including deskmount feet or mount plate
  • Weight : 41.27 oz (1.17 kg)
  • Quality of Service

Advanced Power Save (U-Access PointSD)

  • WMM Access Categories with DSCP and 802.1p support
  • Layer 7 application traffic identification and shaping

Mobility

  • PMK, OKC, and 802.11r for fast Layer 2 roaming
  • Distributed or centralized Layer 3 roaming

Analytics

  • Embedded location analytics reporting and device tracking
  • Global L7 traffic analytics reporting per network, per device, and per application

LED Indicators

  • 1 power/booting/firmware upgrade status
