Description

Meraki MS355-48 Dubai

The Meraki MS355-48 Dubai is a multi-gigabit switch line designed to help prepare Organizations for the increased bandwidth requirements of the upcoming 802.11ax wireless standard with high-count mGig switch ports and increased switching capacity to meet the demands of next generation access points. Networks with sizeable wireless deployments such as universities, hospitals, and large public complexes like transportation centers can all benefit from the increased bandwidth capabilities of the MS355.

With 4 different models, each with multiple mGig RJ45 ports capable of negotiating up to 10Gbps, 40G QSFP+ ports, and dedicated 100G hardware stacking ports, the Meraki MS355-48 Dubai line is fully ready to support the future deployment of 802.11ax wireless infrastructure across a variety of different environments.

Meraki MS355-48X2 Specifications
Interfaces	24 × 100M/1/2.5/5/10G Ethernet RJ45 24 × 1G Ethernet RJ45 4 × 10G SFP+ 2 × 40G QSFP+ uplinks 2 × 100G QSFP28 stacking ports Auto negotiation and crossover detection
Management	Managed via the Web with the Meraki cloud management platform Integrated with Meraki Wireless and complete portfolio of IT products and solutions Zero-touch remote provisioning (no staging needed) Detailed historical per-port and per-client usage statistics Operating system, device, and hostname fingerprinting SNMP and SYSLOG support for integration with other network management solutions Automatic firmware upgrades with scheduling control
Remote Diagnostics	Email, SMS and Mobile push notification alerts Ping, traceroute, cable testing, and link failure detection with alerting Remote packet capture Dynamic and interactive network discovery and topology Combined event and configuration change logs with instant search
Scalable Stacking	Physical stacking of up to 8 switches with 400 Gbps stacking bandwidth on all models Virtual Stacking supports thousands of switch ports in a single logical stack for unified management, monitoring, and configuration
Ethernet Switching Capabilities	802.1p Quality of Service, 8 queues (w/ 6 configurable for DSCP-to-CoS mapping) 802.1Q VLAN and trunking support for up to 4,094 VLANs 802.1w, 802.1D Rapid Spanning Tree Protocol (RSTP, STP) STP Enhancements : BPDU guard, Root guard, Loop guard, UDLD Broadcast storm control 802.1ab Link Layer Discovery Protocol (LLDP) and Cisco Discovery Protocol (CDP) 802.3ad Link aggregation with up to 8 ports per aggregate, Multichassis aggregates supported on stacked switches Port mirroring IGMP snooping for multicast filtering MAC forwarding entries : 32K
Security	Integrated multi-factor authentication for Dashboard management Role-based access control (RBAC) with granular device and configuration control Corporate-wide password policy enforcement IEEE 802.1X RADIUS and MAB, hybrid authentication, and RADIUS server testing Single-Host/Multi-Domain/Multi-Host/Multi Authentication Port security : Sticky MAC, MAC whitelisting DHCP snooping, detection and blocking, Dynamic ARP Inspection IPv4 and IPv6 ACLs
Performance	Switching capacity : 688 Gbps Forwarding rate : 512 mpps Jumbo frame support (9600 byte Ethernet frame) Flow control support
Layer 3	Static routing, OSPFv2 Multicast routing Warm spare (VRRP) DHCP Relay, DHCP Server
Power	Power input : 100-240 VAC, 47-63 Hz Power consumption : 110-1793 W max 48V DC 802.3af/802.3at Power-over-Ethernet (PoE/PoE+/UPoE) available on all ports (maximum of 60W per port for UPoE) for powered switches
Mounting	1U rack-mountable with included rack mount hardware 4 post rack mount support
Environment	Operating temperature : 0°C to 45°C Humidity : 5 to 95% non-condensing Variable speed fans
Physical Specifications (HxWxD)	1.72” × 19.08” × 20.34” (4.37cm × 48.46cm × 51.66cm) 13.14 lb (5.96 kg)
MTBF (at 25°C)	330,228
