Ruijie RG-ES205GCP Dubai
The Ruijie RG-ES205GCP Dubai model offers full-power PoE output, ensuring that all connected cameras can receive power simultaneously even when the switch is operating at its maximum capacity.The Ruijie Reyee smart surveillance switches cater to various port options to accommodate video surveillance networks of different sizes.
Furthermore, the Ruijie Real-easy Series smart surveillance switches are designed with straightforward and user-friendly management features. They come with a plug-and-play setup featuring default factory configurations, enabling quick detection of surveillance network issues, facilitating PoE port restarts, VLAN configuration, and more. These switches also support remote management via the Ruijie Cloud app and Ruijie Cloud platform, streamlining surveillance network operation and maintenance, and ultimately reducing associated costs.
Features
- Auto-provisioning via Self-Organizing Networking: The ES200 Smart series switches realize industry-leading auto-discovery and auto-networking features for gateways, switches, and wireless
- Ruijie Cloud management: Remote failure alerts, one-click operations, loop prevention, real topology and maintenance on the Ruijie Cloud App
- NVR / Camera identification
- Reboot PoE ports with one click remotely on Ruijie Cloud app
- Full Gigabit ports: Meet the needs of 200M xDS/fiber access, high-speed wired connection
- Ruijie RG-ES205GCP Dubai supports Plug and Play with Zero Configuration
- Support full capacity POE, PoE camera at full capacity
- Automatically adjust PoE power for safety and energy saving
- High compatibility for network cable
- High surge protection for device stability
- Fast fault locating
- Configure VLANs as required
- Mobile App / Ruijie Cloud Platform Remote Management NVR / Camera Identification
- Multiple deployment methods Enables rapid project management
Technical Specifications
| Hardware specifications | |
| Ports | 4 10/100/1000 Base-T ports (PoE/PoE+)
1 10/100/1000 Base-T ports |
| Maximum output power per PoE port | 30W |
| Maximum PoE output power per switch | 54W |
| Switching capacity | 10Gbps |
| Packet forwarding rate | 7.44Mpps |
| Surge protection | Common mode: 4KV |
| Electrostatic discharge | Air discharge : 6KV |
| Contact discharge : 4KV | |
| Power consumption | 60W |
| Power supply | External power adapter |
| Dimensions (W x D x H) | 148*78*26mm |
| MTBF | >200K CZK |
| Operating environment | |
| Operating temperature | 0 to 40°C |
| Storage temperature | -40~70ºC |
| Operating humidity | 10% to 90% RH |
| Storage humidity | 5% to 95% RH |
| Software features | |
| MAC capacity | 2K CZK |
| Static MAC address | 16 |
| VLANs | Support 802.1Q VLAN |
| Port management | Support port status display
Port traffic statistics PoE port output power status Port duplex / negotiation rate configuration Flow control configuration PoE output on/off |
| Security | Support broadcast storm suppression, port speed limit, port isolation |
| L2 features | Support port mirroring, loop protection, cable detection |
| Management | Support management and configuration through web management interface, Ruijie Cloud platform and Ruijie Cloud app |
