Tplink Archer-AX72 Dubai

Tplink Archer-AX72 Dubai

The Tplink Archer-AX72 Dubai scaled armor design includes a dedicated area of 167 cm² (25 in²) for efficient heat dissipation, maximizing the machine’s overall performance.

Category:

Description

Tplink Archer-AX72 Dubai

The Tplink Archer-AX72 Dubai comes with an advanced and efficient 64-bit Qualcomm CPU, enhancing data processing and minimizing network latency. This results in a strong and stable network connection. With the ability to handle multiple devices simultaneously, your home network is future-proofed by the combination of OFDMA and MU-MIMO technologies, allowing for greater device connectivity. The integrated MU-MIMO Technology enables data transmission to multiple devices simultaneously through multiple streams, while the modern slant rectangle design adds a contemporary touch. Additionally, the scaled armor design includes a dedicated area of 167 cm² (25 in²) for efficient heat dissipation, maximizing the machine’s overall performance.

Features

  • Gigabit Wi-Fi for 8K Streaming : 5400 Mbps Wi-Fi for faster browsing, streamings, and downloading, all at the same time.
  • Fully Featured Wi-Fi 6 : Equips with the top structure of 4T4R and HE160 on the 5 GHz band to enable 4.8 Gbps ultra-fast connection.
  • Connect 100+ Devices : Supports MU-MIMO and OFDMA to reduce congestion and quadruple the average throughput.
  • Extensive Coverage :  Tplink Archer-AX72 Dubai is equipped with 6× antennas and Beamforming which ensure broad coverage.
  • HomeShield : TP-Link’s premium security services keep your home network safe with cutting-edge features for network and IoT protection.
  • More Vents, Less Heat : Improved vents area unleash the full power of the whole machine.
  • USB Sharing : 1× USB 3.0 port enables easy media sharing and private cloud building.
  • Easy Setup : Set up the router in minutes with Tether app.

Technical Specs

Standards Wi-Fi 6

IEEE 802.11ax/ac/n/a 5 GHz

IEEE 802.11ax/n/b/g 2.4 GHz

WiFi Speeds AX5400

5 GHz : 4804 Mbps (802.11ax, HE160)

2.4 GHz : 574 Mbps (802.11ax)

WiFi Range 3 Bedroom Houses

6× Fixed High-Performance Antennas

Multiple antennas form a signal-boosting array to cover more directions and large areas

Beamforming

Concentrates wireless signal strength towards clients to expand WiFi range

High-Power FEM

Improves transmission power to strengthen signal coverage

4T4R

Multiple streams in the same band strengthen the fault tolerance in transmission

WiFi Capacity High

Dual-Band

Allocate devices to different bands for optimal performance

4×4 MU-MIMO

Simultaneously communicates with multiple MU-MIMO clients

OFDMA

Simultaneously communicates with multiple Wi-Fi 6 clients

Airtime Fairness

Improves network efficiency by limiting excessive occupation

DFS

Access an extra band to reduce congestion

6 Streams

Connect your devices to more bandwidth

Working Modes Working Modes

Access Point Mode

HARDWARE
Processor 1 GHz Dual-Core CPU
Ethernet Ports 1× Gigabit WAN Port

4× Gigabit LAN Ports

USB Support 1× USB 3.0 Port

Supported Partition Formats :

NTFS, exFAT, HFS+, FAT32

Supported Functions :

Apple Time Machine

FTP Server

Media Server

Samba Server

Buttons Wi-Fi On/Off Button

Power On/Off Button

LED On/Off Button

WPS Button

Reset Button

Power 12 V ⎓ 2.5 A
SECURITY
WiFi Encryption SPI Firewall

Access Control

IP & MAC Binding

Application Layer Gateway

HomeShield Security

Real-Time IoT Protection

Malicious Site Blocker

Intrusion Prevention System

DDoS Attack Prevention

Home Network Scanner

Guest Network 1× 5 GHz Guest Network

1× 2.4 GHz Guest Network

VPN Server OpenVPN

PPTP

SOFTWARE
Protocols IPv4

IPv6

OneMesh OneMesh Supported

Without replacing your existing devices or buying a whole new WiFi ecosystem, OneMesh helps you create a more flexible network that covers your entire home with TP-Link OneMesh products.

Parental Controls HomeShield Parental Controls

Custom Profiles

Professional Content Filter Library

Family Time

Bedtime

Off Time

Time Rewards

Family Online Time Ranking

Pause the Internet

Weekly and Monthly Reports

WAN Types Dynamic IP

Static IP

PPPoE

PPTP

L2TP

Quality of Service QoS by Device
Cloud Service Auto Firmware Upgrade

TP-Link ID

DDNS

NAT Forwarding Port Forwarding

Port Triggering

DMZ

UPnP

Virtual Server

IPTV IGMP Proxy

IGMP Snooping

Bridge

Tag VLAN

DHCP Address Reservation

DHCP Client List

Server

DDNS TP-Link

NO-IP

DynDNS

Management Tether App

Webpage

PHYSICAL
Dimensions (W×D×H) 10.7 × 5.8 × 1.9 in

(272.5 × 147.2 × 49.2 mm)

Package Contents Wi-Fi Router Archer AX72

Power Adapter

RJ45 Ethernet Cable

Quick Installation Guide

OTHER
System Requirements Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser

Cable or DSL Modem (if needed)

Subscription with an internet service provider (for internet access)

Certifications FCC, CE, RoHS
Environment Operating Temperature : 0℃~40℃ (32℉ ~104℉)

Storage Temperature : -40℃~70℃ (-40℉ ~158℉)

Operating Humidity : 10%~90% non-condensing
