The Tplink MC112CS Dubai is proficient in transmitting data over extended distances through single-mode fiber, achieving impressive ranges of up to 20 kilometers.



Category:

Description

Tplink MC112CS Dubai

The Tplink MC112CS Dubai serves as a media converter designed to seamlessly transform 100BASE-FX fiber to 100Base-TX copper media and vice versa. By implementing Wavelength Division Multiplexing (WDM) technology, the MC112CS efficiently employs a single fiber cable for both data transmission and reception, leading to significant cost savings on cabling expenditures.

Compliant with IEEE 802.3u standards governing 10/100Base-TX and 100Base-FX, the Tplink MC112CS Dubai is tailor-made for utilization with single-mode fiber cables, featuring the SC-Type connector. This media converter also excels in supporting the longwave (LX) laser specification at a full wire-speed forwarding rate. The Tplink MC112CS Dubai operates at 1310nm for data transmission and 1550nm for data reception. As a result, the corresponding end device working in conjunction with the Tplink MC112CS Dubai should employ 1550nm for data transmission and 1310nm for data reception. TP-LINK’s MC111CS media converter is just one example of a compatible device that can be paired with the Tplink MC112CS Dubai.

Additional noteworthy features of this module encompass its capacity to operate as a standalone device, eliminating the need for a chassis (no chassis required), support for Auto MDI/MDI-X on the TX port, auto negotiation of duplex mode on the TX port, and the presence of front panel status LEDs. The Tplink MC112CS is proficient in transmitting data over extended distances through single-mode fiber, achieving impressive ranges of up to 20 kilometers.

Features

  • Complies with 802.3u 10/100Base-TX, 100Base-FX standards
  • Link Fault Passthrough and Far End Fault minimize the loss caused by link failure timely
  • Adopts WDM technology, transmitting and receiving data on one single fiber
  • Extends fibre distance up to 20km

Specifications

MEDIA CONVERTER & MODULE
Standards and Protocols IEEE 802.3i, IEEE 802.3u
Basic Function Adopts WDM technology

Half/Full-Duplex transfer mode for FX port

Extends fiber distance up to 20km

Ports 1 100M SC/UPC port

1 10/100M RJ45 port (Auto MDI/MDIX)

Wave Length 1310nm Tx/1550nm Rx
WDM TX 1310nm
WDM RX 1550nm
Network Media 10BASE-T UTP category 3, 4, 5 cable (maximum 100m)

EIA/TIA-568 100Ω STP (maximum 100m)

Network Media 100BASE-T UTP category 5, 5e cable (maximum 100m)

EIA/TIA-568 100Ω STP (maximum 100m)

Network Media 100BASE-FX Single-mode Fiber
LED Indicators PWR, Link/Act
Dimensions (W*D*H) 3.7*2.9*1.1 in. (94.5*73.0*27.0 mm)
Power Supply External Power Adapter
Max Power Consumption 2.41W
Safety & Emission FCC, CE, RoHS
Package Contents Media Converter MC112CS

Power Adapter

Installation Guide

Environment Operating Temperature : 0℃~40℃ (32℉~104℉)

Storage Temperature : -40℃~70℃ (-40℉~158℉)

Operating Humidity : 10%~90% non-condensing

Storage Humidity : 5%~90% non-condensing
