Tplink OC300 Dubai

Tplink OC300 Dubai

The Tplink OC300 Dubai Omada Hardware Controller by TP-Link Efficiently oversee all your business’s network devices, including JetStream switches, Omada access points, SafeStream Routers, and more, via a unified and centralized cloud solution.

Category:

Description

Tplink OC300 Dubai

The Tplink OC300 Dubai Omada Hardware Controller by TP-Link Efficiently oversee all your business’s network devices, including JetStream switches, Omada access points, SafeStream Routers, and more, via a unified and centralized cloud solution. This controller seamlessly integrates into your network infrastructure through its two Gigabit Ethernet ports.

Designed to cater to various sectors, including hospitality, education, retail, and office environments, the Tplink OC300 Dubai empowers you to effectively manage up to 500 Omada devices, serving 15,000 clients across multiple sites. You can achieve this control from virtually anywhere and at any time using the Omada App. Alternatively, the cloud portal offers you the means to configure, monitor, and maintain your network, complete with remote firmware updates and automated scheduled tasks.

With its straightforward plug-and-play design, the Tplink OC300 Dubai is engineered for rapid integration into your network and arrives with a rackmount kit for added convenience. The inclusion of a USB 3.1 Gen 1 Type-A port enables automated configuration backups to a flash drive, enhancing data security and providing peace of mind.

Features

        Omada App

    • Using the Omada mobile app, you can remotely access and configure your Tplink OC300 Dubai from your phone from anywhere in the world at any time.

       Dashboard

    • The detailed dashboard makes it easy to check your real-time network status, network usage, and traffic distribution on the Tplink OC300 Dubai. Network topology helps administrators to quickly see and troubleshoot connections at a glance.

Management Features

  • Automatic Device Discovery
  • Batch Configuration
  • Batch Firmware Upgrading
  • Intelligent Network Monitoring
  • Abnormal Event Warnings
  • Unified Configuration
  • Reboot Schedule
  • Captive Portal Configuration

Specifications

Interface 2 x RJ45 Gigabit Ethernet Port 1 x USB 3.1 Gen 1 Type-A Port
Computer
Processor 1.2 GHz A72 Quad-Core
Flash Memory 8 GB eMMC
RAM 2 GB DDR4
Network
System Management
  • Max Sites : 100
  • Max Accounts : 1000
  • Max Local Accounts : 500
  • Max Cloud Accounts : 500
  • Max Vouchers : 50,000
  • Max Local Users : 50,000
  • Max WLAN Groups : 500
  • Max SSIDs : 16 per Site
  • Max ACL :
    • Router : 64; Switch : 32; EAP : 16
  • Max Free Authentication : 32 per Site
  • Max Pre-Authentication Access : 32 per Site
  • Max Authentication Free Policy : 96 per Site
  • Max Reboot Schedule : 8 per Site
  • Max PoE Schedule : 8 per Site
  • Max MAC Filter Groups : 8 per Site
  • Max MAC Addresses : 500 per Group (4000 per Controller)
  • Max VPN : 64 per Site
  • Max Static Routing : 64 per Site
  • Max Policy Routing : 64 per Site
Environmental & Power
Operating Temperature 32 to 122°F / 0 to 50°C
Storage Temperature -40 to 158°F / -40 to 70°C
Operating Humidity 10 to 90%
Storage Humidity 5 to 90%
AC Power 100 to 240 VAC @ 50/60 Hz, 0.6 A
Power Consumption 9 W (Typical) 14.8 W (Max)
General
Material of Construction Metal
Dimensions 11.6 x 7.1 x 1.7″ / 294 x 180 x 44 mm
Packaging Info
Package Weight 4 lb
Box Dimensions (LxWxH) 15.75 x 9.75 x 3.25″
