Tplink TL-FC111B20 Dubai

Tplink TL-FC111B20 Dubai

The Tplink TL-FC111B20 Dubai stands as a 100M media converter, equipped with both a 100M RJ-45 port and a 100M SC fiber port, facilitating seamless conversion between electrical and optical signals.

Category:

Description

Tplink TL-FC111B20 Dubai

The Tplink TL-FC111B20 Dubai stands as a 100M media converter, equipped with both a 100M RJ-45 port and a 100M SC fiber port, facilitating seamless conversion between electrical and optical signals. This versatility makes it an ideal choice for long-distance data transmission through optical fiber, making it particularly suitable for commercial applications like park security monitoring and wireless networking.

What sets the Tplink TL-FC111B20 Dubai apart is its adoption of WDM (wavelength division multiplexing) technology. This innovative technology enables efficient bidirectional data transmission over a single fiber at distances of up to 20km (12.4 miles), resulting in substantial cost savings for cable deployment. Specifically, the Tplink TL-FC111B20 Dubai transmits data at a wavelength of 1310nm and receives data at 1550nm over optical fiber. Its counterpart at the other end of the connection operates in tandem, receiving data at 1310nm and sending data at a wavelength of 1550nm. This unique configuration optimizes data transmission efficiency and cost-effectiveness.

Features

  • Complies with 802.3u 10/100Base-TX, 100Base-FX standards
  • Auto-negotiation of Half-Duplex/Full-Duplex transfer mode
  • 9/125 μm SMF (Single-Mode Fiber)
  • Bidirectional WDM communication on a single fiber
  • Ranges up to 20km (12.4 miles)
  • Work with TL-FC111B-20 as a pair

Technical Specs

HARDWARE FEATURES
Interface 1× 100 Mbps SC Fiber Port

1× 10/100 Mbps RJ45 Port (Auto MDI/MDIX)

Network Media 100BASE-Tx : 2-pair UTP/STP of Cat. 5 or above (≤100 m)
Power Supply External Power Adapter : 5 V/0.6 A
LED PWR, Link/Act
Dimensions ( W x D x H ) 94.5*73*27 mm
Wave Length 1310 nm TX, 1550 nm RX
MEDIA CONVERTER & MODULE
Standards and Protocols IEEE 802.3, IEEE 802.3i, IEEE802.3u
Basic Function Auto-negotiation of half-duplex / full-duplex transfer mode

Full-duplex flow control (IEEE 802.3x)

Half-duplex flow control (Backpressure)

Extends fiber distance up to 20km (12.4 miles)

Ports 1x 100M single SC/UPC port

1x 10/100M RJ45 port (Auto MDI/MDIX)

WDM TX 1310 nm
WDM RX 1550 nm
Network Media 10BASE-T UTP category 3, 4, 5 cable (maximum 100m)

EIA/TIA-568 100Ω STP (maximum 100m)

Network Media 100BASE-T UTP category 5, 5e cable (maximum 100m)

EIA/TIA-568 100Ω STP (maximum 100m)

Network Media 100BASE-FX Single-mode fiber
LED Indicators PWR, Link/Act
Dimensions (W*D*H) 3.7 × 2.9 × 1.1 in.
(95 × 73 × 27 mm)
Power Supply External Power Adapter : 5 V/0.6 A
Safety & Emission FCC, CE, RoHS
Fiber Type 9/125 μm single-mode fber (≤20 km)
Environment Operating Temperature : 0℃~50℃ (32℉~122℉)

Storage Temperature : -40℃~70℃ (-40℉~158℉)

Operating Humidity : 10%~90% non-condensing

Storage Humidity : 5%~90% non-condensing

NETWORK
Standards and Protocols IEEE802.3, IEEE802.3i, IEEE802.3u
ENVIRONMENT
Operating Temperature 0˚C to 50˚C (32˚F to 122˚F)
Storage Temperature -40˚C to 70˚C (-40˚F to 158˚F)
Operating Humidity 10% to 90% RH non-condensing
Storage Humidity 5% to 90% RH non-condensing
OTHERS
Package Contents Media Converter TL-FC111B-20

Power Adapter

Installation Guide
