Tplink TL-FC311B20 Dubai
The Tplink TL-FC311B20 Dubai Gigabit WDM Media Converter empowers you to seamlessly convert Gigabit Ethernet RJ45 electrical signals into optical signals using a Gigabit SC fiber port. This robust device is meticulously designed to support long-distance video surveillance and various data transmissions, boasting an impressive range of up to 12.4 miles when utilizing a 9/125µm single-mode fiber cable, or extending up to 328 feet with Cat 5/5e Ethernet cables via its RJ45 port.
Operating at a frequency wavelength of 1310nm for transmission and 1550nm for data reception, the Tplink TL-FC311B20 Dubai perfectly complements the TP-Link TL-FC311A-20 WDM Media Converter. It automatically negotiates between half- and full-duplex modes, ensuring a seamless and efficient data transfer experience.
In essence, the Tplink TL-FC311B20 Dubai serves as a gigabit media converter, featuring a gigabit RJ-45 port and a gigabit SC fiber port, facilitating the conversion between electrical and optical signals. This versatile capability lends itself well to long-distance data transmission through optical fiber, making it an ideal solution for commercial applications such as park security monitoring and wireless networking.
Quick Features
- Ethernet 1000Base-SC, Ethernet 1000Base-T, WDM Cabling
- Supports Gigabit Ethernet Networking
- Data Transfer Speeds up to 1Gbps
Specifications
| NETWORK | |
| Standards and Protocols | IEEE 802.3, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3z |
| ENVIRONMENT | |
| Operating Temperature | 0˚C to 50˚C (32˚F to 122˚F) |
| Storage Temperature | -40˚C to 70˚C (-40˚F to 158˚F) |
| Operating Humidity | 10% to 90% RH non-condensing |
| Storage Humidity | 5% to 90% RH non-condensing |
| HARDWARE FEATURES | |
| Interface | 1× Gigabit SC Fiber Port
1× 10/100/1000 Mbps RJ45 Port (Auto MDI/MDIX) |
| Network Media | Single-mode Fiber
UTP category 5, 5e cable (maximum 100m) |
| Power Supply | External Power Adapter: 5 V/0.6 A |
| LED | PWR, Link/Act |
| Dimensions ( W x D x H ) | 3.7 × 2.9 × 1.1 in (95 × 73 × 27 mm) |
| Wave Length | 1310 nm TX
1550 nm RX |
| MEDIA CONVERTER & MODULE | |
| Fiber Type | 9/125 μm single-mode fiber |
| OTHERS | |
| Package Contents | Media Converter TL-FC311B-20
Power Adapter Installation Guide |
