Tplink TL-SF1008P Dubai

Tplink TL-SF1008P Dubai

The Tplink TL-SF1008P Dubai Fast Ethernet Switch is tailored for use in small office/home office (SOHO) environments or workgroup setups. With all 24 ports supporting auto MDI/MDIX, you don’t need to worry about cable types—just plug and play.

Category:

Description

Tplink TL-SF1008P Dubai

The Tplink TL-SF1008P Dubai Fast Ethernet Switch is tailored for use in small office/home office (SOHO) environments or workgroup setups. With all 24 ports supporting auto MDI/MDIX, you don’t need to worry about cable types—just plug and play. What’s more, it features innovative energy-efficient technology that can reduce power consumption by up to 67%, making it an environmentally-friendly choice for your business network.

The Tplink TL-SF1008P Dubai is an 8-port unmanaged switch with 10/100Mbps capabilities. It requires no configuration and includes 4 Power over Ethernet (PoE) ports. These PoE ports are capable of automatically detecting and supplying power to devices compliant with the IEEE 802.3af standard. This means that both electrical power and data are transmitted over a single cable, allowing you to expand your network to locations where traditional power sources may be lacking. This is especially useful for connecting devices such as access points (APs), IP cameras, or IP phones in areas without readily available power outlets.

Features

High Performance

The Tplink TL-SF1008P Dubai Fast Ethernet Switch provides 24 10/100Mbps Auto-Negotiation RJ45 ports. All ports support Auto MDI/MDIX function, eliminating the need for crossover cables or Uplink ports. Featuring non-blocking switching architecture, TL-SF1024M forwards and filters packets at full wire-speed for maximum throughput. And IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode alleviate the traffic congestion and make TL-SF1024M work reliably.

Easy to Use

The auto features of this switch make installation plug and play and hassle-free. No configuring is required. Auto MDI/MDIX eliminates the need for crossover cables. Auto-negotiation on each port senses the link speed of a network device (10, 100 Mbps) and intelligently adjusts for compatibility and optimal performance.

Power over Ethernet

4 of the 8 Auto-Negotiation RJ45 ports (port-1 to port-4) of the switch support Power over Ethernet (PoE) function. These PoE ports can automatically detect and supply power with those IEEE 802.3af compliant Powered Devices (PDs).

  • Overload Arrangement
    • The Tplink TL-SF1008P Dubai has the priority function which will help protect the system when the system power is overloaded. If all PoE PDs power consumption is >= 57W, a priority will be arranged among the PoE ports, then the system will cut o‑ the power of the lowest-priority port.
  • Port Priority Function
    • Priority (port-1=port-2=port-3>port-4) :  This function will help to ensure the normal operation of the system, it means Port 4 will be cut off when all total PoE PDs power consumption exceed 57W. For an example, Port 1, 2 and 4 is using 15.4W (maximum power for per port is 15.4W); the system power is 46.2W in total. If there is an additional PD inserted to Port 3 with 12W, and then the system will cut off the power of Port 4 because of the overloaded power, this means Port 1, 2 will use 15.4W, and Port3 will use 12W, no power will be supplied to Port 4.

Technical Specs

HARDWARE FEATURES
Interface 8× 10/100 Mbps RJ45 Ports (4× 10/100 Mbps 802.3af/at PoE+ ports)

AUTO Negotiation

AUTO MDI/MDIX

Network Media 10BASE-T : UTP category 3, 4, 5 cable (maximum 100m)

EIA/TIA-568 100Ω STP (maximum 100m)

100BASE-TX : UTP category 5, 5e cable (maximum 100m)

EIA/TIA-568 100Ω STP (maximum 100m)

Fan Quantity Fanless
Physical Security Lock Yes
External Power Supply External Power Adapter (Output : 53.5 V DC / 1.31 A)
Packet Forwarding Rate 1.1904 Mpps
PoE Ports (RJ45) Standard : 802.3 af/at compliant

PoE Ports : Ports 1–4

Power Supply : 66 W

Mac Address Table 2K
Jumbo Frame 2 KB
Switching Capacity 1.6 Gbps
Dimensions ( W x D x H ) 6.7 × 3.9 × 1.1 in (171 × 98 × 27 mm)
Max Power Consumption 2.27 W (220 V/ 50 Hz. no PD connected)

75.33 W (220 V/ 50 Hz. with 66 W PD connected)

Max Heat Dissipation 7.74 BTU/h(no PD connected)

256.88 BTU/h(with 66 W PD connected)

SOFTWARE FEATURES
Transmission Method Store-And-Forward
Advanced Functions Extend Mode Button (Ports 1–4)

Priority Mode Button (Ports 1–2)

PoE Auto Recovery Button (Ports 1–4)

Mac Address Auto-Learning and Auto-Aging

OTHERS
Certification FCC, CE, RoHS
Package Contents TL-SF1008P, Power Adapter, Installation Guide, Rubber Feet
Environment Operating Temperature : 0–40 ℃ (32–104 ℉)

Storage Temperature : -40–70 ℃ (-40–158 ℉)

Operating Humidity : 10–90% RH non-condensing

Storage Humidity : 5–90% RH non-condensing
