The Tplink TL-SF1024D Dubai 24-Port 10/100Mbps Switch offers a cost-effective, high-performance, and user-friendly solution for seamlessly upgrading your outdated network to a 100Mbps network. With auto MDI/MDIX support on all 24 ports.

Category:

Description

Tplink TL-SF1024D Dubai

The Tplink TL-SF1024D Dubai 24-Port 10/100Mbps Switch offers a cost-effective, high-performance, and user-friendly solution for seamlessly upgrading your outdated network to a 100Mbps network. With auto MDI/MDIX support on all 24 ports, you can simply plug and play without worrying about cable types. Additionally, its innovative energy-efficient technology can reduce power consumption by up to 75%, and 80% of its packaging materials are recyclable, making it an environmentally-friendly choice for your business network.

Key Features:

  1. TP-LINK Green Technology: The Tplink TL-SF1024D Dubai, belonging to the new generation, incorporates cutting-edge energy-efficient technologies that significantly enhance network capacity while minimizing power consumption. It dynamically adapts power usage based on link status and cable length, effectively reducing the carbon footprint of your network. Moreover, it complies with the EU’s RoHS directive, which restricts the use of hazardous materials. Additionally, 80% of its packaging materials are recyclable.

  2. High Performance: Featuring a rack-mountable steel case design and a safety-certified internal power supply, the Tplink TL-SF1024D Dubai stands out as a robust and cost-effective solution for environments with fewer than 16 users. Its non-blocking switching architecture ensures packets are forwarded and filtered at full wire-speed, maximizing throughput. Furthermore, IEEE 802.3x flow control is employed for Full Duplex mode, while backpressure is utilized for Half Duplex mode, effectively managing traffic congestion and ensuring the reliable performance of the TL-SF1024D.
  3. User-Friendly: The Tplink TL-SF1024D Dubai fast ethernet switch simplifies installation with its auto features, offering a hassle-free and plug-and-play experience. No manual configuration is required. Auto MDI/MDIX eliminates the need for crossover cables, and auto-negotiation on each port intelligently detects the network device’s link speed (10 or 100 Mbps) and adjusts for compatibility and optimal performance automatically.

Technical Specs

HARDWARE FEATURES
Standards and Protocols IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
Interface 24 10/100Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX)
Network Media 10BASE-T : UTP category 3, 4, 5 cable (maximum 100m)

100BASE-TX : UTP category 5, 5e or above cable (maximum 100m)

Fan Quantity Fanless
Power Supply External Power Adapter(Output : 9VDC/0.6A)
Power Consumption Maximum : 3.2W
Dimensions ( W x D x H ) 11.6*7.1*1.7 in. (294*180*44 mm)
Mounting Rack Mountable
Max Power Consumption 3.19W(220V/50Hz)
Max Heat Dissipation 10.88BTU/h
PERFORMANCE
Switching Capacity 4.8Gbps
Packet Forwarding Rate 3.57Mpps
MAC Address Table 8K
Buffer Memory 2Mb
Green Technology Innovative energy-efficient technology saves power up to 75%
Transfer Method Store-and-Forward
OTHERS
Certification FCC, RoHS
Package Contents 24-Port 10/100Mbps Desktop/Rackmount Switch

Power Cord

Installation Guide

Rackmount Kit

Rubber Feet

Environment Operating Temperature : 0℃~40℃ (32℉~104℉)

Storage Temperature : -40℃~70℃ (-40℉~158℉)

Operating Humidity : 10%~90% non-condensing

Storage Humidity : 5%~90% non-condensing
