Tplink TL-SF1024M Dubai

Tplink TL-SF1024M Dubai

The Tplink TL-SF1024M Dubai 24-Port 10/100Mbps Desktop Switch is tailor-made for SOHO (Small Office/Home Office) and workgroup users. With every one of its 24 ports equipped with auto MDI/MDIX support, there’s no need for cable type concerns.

Category:

Description

Tplink TL-SF1024M Dubai

The Tplink TL-SF1024M Dubai 24-Port 10/100Mbps Desktop Switch is tailor-made for SOHO (Small Office/Home Office) and workgroup users. With every one of its 24 ports equipped with auto MDI/MDIX support, there’s no need for cable type concerns—just plug and play. Additionally, its cutting-edge energy-efficient technology can reduce power consumption by up to 67%, making it a sustainable and eco-friendly choice for your business network.

Features

High Performance

The Tplink TL-SF1024M Dubai Fast Ethernet Switch provides 24 10/100Mbps Auto-Negotiation RJ45 ports. All ports support Auto MDI/MDIX function, eliminating the need for crossover cables or Uplink ports. Featuring non-blocking switching architecture, TL-SF1024M forwards and filters packets at full wire-speed for maximum throughput. And IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode alleviate the traffic congestion and make TL-SF1024M work reliably.

Easy to Use

The auto features of the Tplink TL-SF1024M Dubai switch make installation plug and play and hassle-free. No configuring is required. Auto MDI/MDIX eliminates the need for crossover cables. Auto-negotiation on each port senses the link speed of a network device (10, 100 Mbps) and intelligently adjusts for compatibility and optimal performance.

Technical Specs

HARDWARE FEATURES
INTERFACE
  • 24 10/100Mbps RJ45 Ports
  • AUTO Negotiation/AUTO MDI/MDIX
FAN QUANTITY Fanless
POWER CONSUMPTION Maximum : 3.68W (220V/50Hz)
EXTERNAL POWER SUPPLY External Power Adapter (Output : 9VDC / 0.6A)
MAC ADDRESS TABLE 8K
DIMENSIONS ( W X D X H ) 8.7 x 5.0 x 1.8 in. ( 222 x 126 x 45 mm)
MAX POWER CONSUMPTION 3.36W(220V/50Hz)
MAX HEAT DISSIPATION 11.46BTU/h
SOFTWARE FEATURES
TRANSFER METHOD Store and Forward
ADVANCED FUNCTIONS
  • Green Technology, saving power up to 67%
  • 802.3X Flow Control, Back Pressure
OTHERS
CERTIFICATION FCC, RoHs
PACKAGE CONTENTS
  • 24-Port 10/100Mbps Desktop Switch TL-SF1024M
  • Power Adapter
  • Installation Guide
ENVIRONMENT
  • Operating Temperature : 0℃~40℃ (32℉~104℉);
  • Storage Temperature : -40℃~70℃ (-40℉~158℉);
  • Operating Humidity : 10%~90% non-condensing;
