Tplink TL-SG1024 Dubai

Tplink TL-SG1024 Dubai

The Tplink TL-SG1024 Dubai 24-Port Gigabit Rackmount Switch by TP-Link is designed for energy efficiency, allowing you to reduce power consumption by up to 25% compared to traditional network switches. It supports a range of IEEE standards.

Category:

Description

Tplink TL-SG1024 Dubai

The Tplink TL-SG1024 Dubai 24-Port Gigabit Rackmount Switch by TP-Link is designed for energy efficiency, allowing you to reduce power consumption by up to 25% compared to traditional network switches. It supports a range of IEEE standards, including 802.3i, 802.3u, 802.3ab, and 802.3x, making it highly versatile and adaptable to various networking needs.

  • 802.3 Compatibility: This switch conforms to IEEE 802.3 standards, which are widely used in local area networks (LANs) for connecting hubs, switches, and routers.
  • IEEE 802.3u (Fast Ethernet): This standard provides fast data transmission at 100 Mbps, compared to the original Ethernet speed of 10 Mbps.
  • IEEE 802.3x (Flow Control): This standard enables you to control traffic flow within the switch, ensuring efficient data transfer.

Featuring 24 x 10/100/1000 Mbps RJ-45 ports, this Gigabit Switch accommodates multiple devices, allowing them to connect to the Internet simultaneously. Its 48 Gbps switching capacity ensures ultra-fast data transfer speeds, while the 8K MAC address table provides ample space to store a large number of MAC addresses. Auto MDI/MDIX support eliminates the need for crossover cables, simplifying connections.

The Tplink TL-SG1024 Dubai operates on 100-240 VAC at 50/60 Hz, consuming a maximum of 14.6W. It boasts a packet forwarding rate of 35.7 Mbps and comes complete with a power cord, rackmount kits, and rubber feet. Plus, it’s backed by a limited 5-year warranty for added peace of mind.

Features

TP-LINK Green Technology The Tplink TL-SG1024 Dubai Gigabit Switch incorporates innovative energy-efficient technologies that significantly enhance your network capacity while reducing power consumption. It dynamically adjusts power usage based on the link status, effectively minimizing the environmental impact of your network. Additionally, it adheres to the EU’s RoHS regulations, which restrict the use of hazardous materials. Furthermore, up to 80% of its packaging materials are recyclable.

High Performance Equipped with 24 Gigabit RJ-45 ports, the Tplink TL-SG1024 Dubai supports high-speed large file transfers and is compatible with 10 Mbps and 100 Mbps Ethernet devices. Its non-blocking switching architecture enables the forwarding and filtering of packets at maximum wire-speed, ensuring exceptional throughput. The inclusion of 10KB Jumbo frame support further enhances the performance of large file transfers. Additionally, IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode alleviate traffic congestion, ensuring the reliable operation of the Tplink TL-SG1024 Dubai. This switch is an excellent choice for upgrading your network to Gigabit speeds while safeguarding your previous investment.

User-Friendly The Tplink TL-SG1024 Dubai Gigabit switch boasts automatic features that simplify installation, making it a hassle-free experience. No complex configurations are needed, and Auto MDI/MDIX eliminates the requirement for crossover cables. Auto-negotiation on each port detects the link speed of connected network devices (10, 100, or 1000 Mbps) and intelligently adjusts for compatibility and optimal performance.

Additional Features:

  • Energy-efficient technology reduces power consumption by up to 25%.
  • 100% Data filtering rate eliminates all error packets.
  • Supports IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode.
  • Non-blocking switching architecture forwards and filters packets at full wire-speed for maximum throughput.
  • 48 Gbps Switching Capacity.
  • Auto-MDI/MDIX eliminates the need for crossover cables.
  • Supports MAC address auto-learning and auto-aging.
  • Supports port N-Way Auto-Negotiation, Store, and Forward.
  • Compact design suitable for desktop use, with rack-mounting capability.
  • Plug-and-play design for straightforward installation.

Technical Specs

Interfaces
Ports 24 x 10/100/1000 Mb/s Gigabit Ethernet (RJ45)
Protocols
Supported Protocols Auto-MDIX/MDI
Transmission Method Store-and-Forward
Jumbo Frames Support 10,000 Bytes
MAC Address Table Size 8K
Standards
Supported IEEE Standards 802.3ab, 802.3i, 802.3u, 802.3x
Performance
Forwarding Rate 35.7 Mpps
Switching Bandwidth 48 Gb/s
Computer
OS Compatibility
  • Windows XP or Later
  • macOS
  • Linux
  • UNIX
Electrical
Power Draw 14.6 W (Active)
AC Input Power 100 to 240 VAC, 50 / 60 Hz
Environmental
Operating Temperature 32 to 104°F / 0 to 40°C
Operating Humidity 10 to 90%
Storage Temperature -40 to 158°F / -40 to 70°C
Storage Humidity 5 to 90%
Certifications RoHS
General
Cooling System Passive
Dimensions 17.3 x 7.1 x 1.7″ / 44 x 18 x 4.4 cm
Packaging Info
Package Weight 5 lb
Box Dimensions (LxWxH) 20.8 x 10 x 3.1″
