Description
Tplink TL-SG1048 Dubai
The Tplink TL-SG1048 Dubai Gigabit Rackmount Switch by TP-Link is expertly crafted to fulfill the demands of even the most rigorous workgroup and departmental connectivity needs. This reliable and user-friendly switch eliminates the complexities of management, offering an impressive array of 48 10/100/1000Mbps ports. The Tplink TL-SG1048 Dubai effortlessly marries user-friendliness with unmatched performance, presenting an outstanding value proposition for network administrators who prioritize top-notch solutions without breaking the budget.
Features
User-Friendly Operation The Tplink TL-SG1048 Dubai gigabit switch boasts automatic features that simplify installation, making it a plug-and-play, hassle-free experience. No configuration is needed. With auto MDI/MDI-X crossover on all ports, you can say goodbye to the need for crossover cables or uplink ports. Each port’s auto-negotiation capability senses the link speed of connected network devices (be it 10, 100, or 1000 Mbps) and adjusts intelligently for compatibility and peak performance. Its compact design is ideal for desktops with limited space, and it’s also rack-mountable for added convenience and safety. Dynamic LED lights provide real-time status updates and facilitate basic fault diagnosis.
High Performance The Tplink TL-SG1048 Dubai boasts a non-blocking wire-speed architecture with an impressive 96Gbps switching capacity, ensuring maximum data throughput. With an 8K MAC address table, it offers scalability even for the most extensive networks. Additionally, it supports 802.3x Flow Control for full-duplex mode, while back pressure flow control for half-duplex mode helps alleviate traffic congestion, guaranteeing reliable data transmission.
TP-LINK Green Technology The Tplink TL-SG1048 Dubai 48-Port Gigabit Rackmount Switch represents a new generation of switches with innovative, energy-efficient technologies that significantly expand your network’s capacity while consuming minimal power. It automatically adjusts power consumption based on link status to minimize your network’s carbon footprint. Furthermore, it complies with RoHS standards, which restrict the use of hazardous materials. Additionally, a substantial portion of the packaging material is recyclable, demonstrating a commitment to environmental responsibility.
Technical Specs
| HARDWARE FEATURES | |
| STANDARDS AND PROTOCOLS | IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x |
| INTERFACE | 48 10/100/1000Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX) |
| NETWORK MEDIA | 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) 100BASE-TX/1000BASE-T: UTP category 5, 5e or above cable (maximum 100m) |
| FAN QUANTITY | 2 |
| POWER SUPPLY | 100-240VAC, 50/60Hz |
| POWER CONSUMPTION | Maximum: 32.3W |
| DIMENSIONS ( W X D X H ) | 17.32*8.7*1.73 in.(440*220*44 mm) |
| PERFORMANCE | |
| SWITCHING CAPACITY | 96Gbps |
| PACKET FORWARDING RATE | 71.4Mpps |
| MAC ADDRESS TABLE | 16K |
| BUFFER MEMORY | 12Mb |
| JUMBO FRAME | 12KB |
| TRANSFER METHOD | Store-and-Forward |
| OTHERS | |
| CERTIFICATION | FCC, CE, RoHS |
| PACKAGE CONTENTS | 48-Port Gigabit Rackmount Switch
Power Cord Installation Guide Rackmount Kits Rubber Feet |
