The Tplink TL-SG108PE Dubai 8-Port Gigabit PoE Compliant Unmanaged Switch from TP-LinkEffortlessly expand your home or small business network to accommodate Power-over-Ethernet (PoE) devices like IP security cameras, VoIP phones.

Category:

Description

Tplink TL-SG108PE Dubai

The Tplink TL-SG108PE Dubai 8-Port Gigabit PoE Compliant Unmanaged Switch from TP-LinkEffortlessly expand your home or small business network to accommodate Power-over-Ethernet (PoE) devices like IP security cameras, VoIP phones, wireless access points, and more. This unmanaged switch boasts eight Gigabit Ethernet ports, with four of them being PoE compliant, supporting up to 15W each, and a collective power budget of 55W. Simultaneously, it offers a substantial 16 Gb/s switching capacity and an 11.9 Mpps forwarding rate to ensure seamless and dependable data transfers among your devices. With its plug-and-play design, the Tplink TL-SG108PE Dubai V2 8-port switch seamlessly integrates into your network without the need for an intricate and time-consuming setup process.

Features

Intelligent Power Management

The built-in intelligent power management system will cut off lower-priority ports’ power when consumption exceeds 55W, helping to ensure that high-priority devices remain operational and protected from power overloads.

High Performance Features

Administrators can designate traffic priority based on the Quality of Service (QoS) rules so that voice and video applications are clear and lag-free. Additionally, IGMP snooping optimizes multimedia traffic for smooth broadcast experiences.

Link Aggregation

Take advantage of multi-Gig connections to compatible devices by using link aggregation to combine ports for higher throughput. You can create up to four groups, comprised of up to four ports each.

Silent Operation

The metal casing and fanless design allow the Tplink TL-SG108PE Dubai to work silently from your desktop to avoid disturbing your work or home environment.

Specifications

Interfaces
Ports 4 x 10/100/1000 Mb/s Gigabit Ethernet (RJ45) PoE

4 x 10/100/1000 Mb/s Gigabit Ethernet (RJ45)

Protocols
Layer Services Supported Layer 2 Support
Supported Protocols Auto-MDIX/MDI

IGMP Snooping

Link Aggregation

Port Mirroring

Transmission Method Store-and-Forward
Jumbo Frames Support 15,000 Bytes
MAC Address Table Size 4K
Multicast Groups 128
VLAN Groups 32
VLAN IDs 4000
Security
Security Features Storm Control
Standards
Supported IEEE Standards 802.1p, 802.3ab, 802.3i, 802.3q, 802.3u, 802.3x
Performance
Forwarding Rate 11.9 Mpps
Switching Bandwidth 16 Gb/s
Priority Queues 4
Packet Buffer 1.5 MB
Electrical
Power Draw 65.2 W (Max)
DC Input Power 48 VDC at 1.25 A
AC Input Power 100 to 240 VAC, 50 / 60 Hz
PoE Power Budget 55 W
PoE per Port 15 W
Power Supply Type External
Environmental
Operating Temperature 32 to 104°F / 0 to 40°C
Operating Humidity 10 to 90%
Storage Temperature -40 to 158°F / -40 to 70°C
Storage Humidity 5 to 95%
General
Cooling System Passive
Material of Construction Metal
Indicator Lights Link/Activity/Speed, PoE, Power
Dimensions 6.2 x 4 x 1″ / 158 x 101 x 25 mm
Packaging Info
Package Weight 1.94 lb
Box Dimensions (LxWxH) 7.8 x 5.7 x 4.9″
