Description
Tplink TL-SG108PE Dubai
The Tplink TL-SG108PE Dubai 8-Port Gigabit PoE Compliant Unmanaged Switch from TP-LinkEffortlessly expand your home or small business network to accommodate Power-over-Ethernet (PoE) devices like IP security cameras, VoIP phones, wireless access points, and more. This unmanaged switch boasts eight Gigabit Ethernet ports, with four of them being PoE compliant, supporting up to 15W each, and a collective power budget of 55W. Simultaneously, it offers a substantial 16 Gb/s switching capacity and an 11.9 Mpps forwarding rate to ensure seamless and dependable data transfers among your devices. With its plug-and-play design, the Tplink TL-SG108PE Dubai V2 8-port switch seamlessly integrates into your network without the need for an intricate and time-consuming setup process.
Features
Intelligent Power Management
The built-in intelligent power management system will cut off lower-priority ports’ power when consumption exceeds 55W, helping to ensure that high-priority devices remain operational and protected from power overloads.
High Performance Features
Administrators can designate traffic priority based on the Quality of Service (QoS) rules so that voice and video applications are clear and lag-free. Additionally, IGMP snooping optimizes multimedia traffic for smooth broadcast experiences.
Link Aggregation
Take advantage of multi-Gig connections to compatible devices by using link aggregation to combine ports for higher throughput. You can create up to four groups, comprised of up to four ports each.
Silent Operation
The metal casing and fanless design allow the Tplink TL-SG108PE Dubai to work silently from your desktop to avoid disturbing your work or home environment.
Specifications
| Interfaces | |
| Ports | 4 x 10/100/1000 Mb/s Gigabit Ethernet (RJ45) PoE
4 x 10/100/1000 Mb/s Gigabit Ethernet (RJ45) |
| Protocols | |
| Layer Services Supported | Layer 2 Support |
| Supported Protocols | Auto-MDIX/MDI
IGMP Snooping Link Aggregation Port Mirroring |
| Transmission Method | Store-and-Forward |
| Jumbo Frames Support | 15,000 Bytes |
| MAC Address Table Size | 4K |
| Multicast Groups | 128 |
| VLAN Groups | 32 |
| VLAN IDs | 4000 |
| Security | |
| Security Features | Storm Control |
| Standards | |
| Supported IEEE Standards | 802.1p, 802.3ab, 802.3i, 802.3q, 802.3u, 802.3x |
| Performance | |
| Forwarding Rate | 11.9 Mpps |
| Switching Bandwidth | 16 Gb/s |
| Priority Queues | 4 |
| Packet Buffer | 1.5 MB |
| Electrical | |
| Power Draw | 65.2 W (Max) |
| DC Input Power | 48 VDC at 1.25 A |
| AC Input Power | 100 to 240 VAC, 50 / 60 Hz |
| PoE Power Budget | 55 W |
| PoE per Port | 15 W |
| Power Supply Type | External |
| Environmental | |
| Operating Temperature | 32 to 104°F / 0 to 40°C |
| Operating Humidity | 10 to 90% |
| Storage Temperature | -40 to 158°F / -40 to 70°C |
| Storage Humidity | 5 to 95% |
| General | |
| Cooling System | Passive |
| Material of Construction | Metal |
| Indicator Lights | Link/Activity/Speed, PoE, Power |
| Dimensions | 6.2 x 4 x 1″ / 158 x 101 x 25 mm |
| Packaging Info | |
| Package Weight | 1.94 lb |
| Box Dimensions (LxWxH) | 7.8 x 5.7 x 4.9″ |
