Description
Tplink TL-SG2008 Dubai
The Tplink TL-SG2008 Dubai 8-Port Gigabit Smart Switch by TP-Link empowers network administrators with comprehensive control over various network operations. Its capabilities, including loopback detection, cable diagnostics, and IGMP snooping, enable efficient and effective traffic management. The eight high-speed Gigabit Ethernet ports ensure reliable wired connections, while the advanced Quality of Service (QoS) features make it straightforward to prioritize traffic, guaranteeing sufficient network resources for bandwidth-intensive tasks.
Features
Layer 2 Features
- Static Link Aggregation/ Link Aggregation Control Protocol (LACP)
- Up to 512 VLANs simultaneously(out of 4K VLAN IDs)
- STP/RSTP/MSTP
- IGMP Snooping
Quality of Service
- 4 priority queues
- Support IEEE 802.1P
- DSCP QoS
- Rate limit feature
Security Strategies
- Access Control List (L2~L4 ACL)
- Port Security
- Storm Control
- SSL and SSH encryptions
Management
- Web-based GUI
- Command Line Interface (Telnet)
- SNMP v1/v2c/v3
- RMON (1, 2, 3, 9 group)
Technical Specs
| Interfaces | |
| Ports | 8 x 10/100/1000 Mb/s Gigabit Ethernet (RJ45) |
| Protocols | |
| Supported Protocols |
|
| Queuing | Strict Priority, Weighted Round Robin (WRR) |
| Jumbo Frames Support | 9,216 Bytes |
| MAC Address Table Size | 8K |
| VLAN Groups | 512 |
| VLAN IDs | 4000 |
| Security | |
| Security Features | Storm Control |
| Standards | |
| Supported IEEE Standards | 802.1d, 802.1p, 802.1q, 802.1s, 802.1w, 802.3ab, 802.3ad, 802.3i, 802.3u, 802.3x |
| Performance | |
| Forwarding Rate | 11.9 Mpps |
| Switching Bandwidth | 16 Gb/s |
| Priority Queues | 4 |
| Computer | |
| OS Compatibility |
|
| Electrical | |
| Power Draw | 6.42 W (Active) |
| AC Input Power | 100 to 240 VAC, 50 / 60 Hz |
| Environmental | |
| Operating Temperature | 32 to 104°F / 0 to 40°C |
| Operating Humidity | 10 to 90% |
| Storage Temperature | -40 to 158°F / -40 to 70°C |
| Storage Humidity | 5 to 90% |
| Certifications | RoHS, as per Manufacturer |
| General | |
| Cooling System | Passive |
| Dimensions | 8.2 x 4.9 x 1″ / 20.9 x 12.6 x 2.6 cm |
| Packaging Info | |
| Package Weight | 2.1 lb |
| Box Dimensions (LxWxH) | 11.024 x 8.898 x 2.677″ |
