The Tplink TL-SG3210 Dubai JetStream 8-Port Gigabit L2 Managed Switch with 2 SFP Slots is designed to simplify the setup, configuration, and management of your network. This JetStream Switch comes equipped with a robust set of security features.

Category:

Description

Tplink TL-SG3210 Dubai

The Tplink TL-SG3210 Dubai JetStream 8-Port Gigabit L2 Managed Switch with 2 SFP Slots is designed to simplify the setup, configuration, and management of your network. This JetStream Switch comes equipped with a robust set of security features, including IP-MAC-Port-VID Binding, ACL, Port Security, DoS Defense, Storm Control, DHCP Snooping, 802.1X Authentication, and Radius authentication, ensuring the security of your network and providing you with peace of mind.

Among the Layer 2 functionalities integrated into the Tplink TL-SG3210 Dubai, you’ll find link aggregation, 4K VLAN, port isolation, and IGMP snooping. Link aggregation allows for parallel connections to increase throughput beyond the capacity of a single connection and offers redundancy in case one link fails. Port isolation enables direct data link layer communication between nodes, facilitating direct communication with a specific node. Lastly, IGMP snooping involves the monitoring of Internet Group Management Protocol (IGMP) network traffic, allowing the network switch to listen in on the IGMP conversation between hosts and routers.

Key Features:

Versatile Full Gigabit 10-Port Configuration: The Tplink-TL-SG3210-Dubai offers a flexible configuration with 8 × 10/100/1000 Mbps RJ45 ports, accompanied by 2× Gigabit SFP slots, ensuring high-speed and dependable connections.

Seamlessly Integrated into Omada SDN: This switch seamlessly integrates with the Omada Software Defined Networking platform, enabling unified control over network devices, including switches, APs, and gateways. You have multiple control options, whether through the Omada Hardware controller, Software Controller, or in Standalone Mode.

Cloud Accessibility: Gain remote cloud access and utilize the Omada app for centralized cloud management of your entire network across different sites. All of this is manageable from a single interface, accessible anywhere, at any time.

SDN Compatibility: Ensure that your devices/controllers are equipped with SDN firmware (or are upgradable). SDN controllers are designed to work exclusively with SDN Access Points, Switches, and Gateways, while non-SDN controllers are compatible only with non-SDN APs. Further details can be found on the TP-Link website.

Enhanced Network Security: Benefit from advanced security features in the Tplink-TL-SG3210-Dubai, which include 802.1Q VLAN, IP-MAC-Port binding, ACL, Port Security, DoS defense, Storm control, DHCP Snooping, 802.1X radius authentication, and more.

L2+ Functionality: The Tplink-TL-SG3210-Dubai supports Static Routing, facilitating efficient routing of internal traffic for optimized network resource utilization.

Standalone Management: Enjoy powerful management capabilities through various channels, including a web interface, CLI (Console Port, Telnet, SSH), SNMP, RMON, and Dual Image for redundancy.

Technical Specs

HARDWARE FEATURES
Interface 8× 10/100/1000 Mbps RJ45 Ports

2× Gigabit SFP Slots

1× RJ45 Console Port

1× Micro-USB Console Port

Fan Quantity Fanless
Power Supply 100-240 V AC~50/60 Hz
Dimensions ( W x D x H ) 11.6×7.1×1.7 in.
(294×180×44 mm)
Mounting Rack Mountable / Desktop
Max Power Consumption 6.8 W
Max Heat Dissipation 23.3 BTU/h
PERFORMANCE
Switching Capacity 20 Gbps
Packet Forwarding Rate 14.89 Mpps
MAC Address Table 8K
Packet Buffer Memory 4.1 Mbit
Jumbo Frame 9 KB
SOFTWARE FEATURES
Quality of Service 8 priority queues

802.1p CoS/DSCP priority

Queue scheduling

SP (Strict Priority)

WRR (Weighted Round Robin)

SP+WRR

Bandwidth Control

Port/Flow based Rating Limiting

Smoother Performance

Action for Flows

Mirror (to supported interface)

Redirect (to supported interface)

Rate Limit

QoS Remark

L2 and L2+ Features Link Aggregation

Static link aggregation

802.3ad LACP

Up to 8 aggregation groups and up to 8 ports per group

Spanning Tree Protocol

802.1d STP

802.1w RSTP

802.1s MSTP

STP Security : TC Protect, BPDU Filter, BPDU Protect, Root Protect, Loop Protect

Loopback Detection

Port-based

VLAN based

Flow Control

802.3x Flow Control

HOL Blocking Prevention

Mirroring

Port Mirroring

CPU Mirroring

One-to-One

Many-to-One

Tx/Rx/Both

L2 Multicast Supports 511 (IPv4, IPv6) IGMP groups

IGMP Snooping

IGMP v1/v2/v3 Snooping

Fast Leave

IGMP Snooping Querier

IGMP Authentication

IGMP Authentication

MVR

MLD Snooping

MLD v1/v2 Snooping

Fast Leave

MLD Snooping Querier

Static Group Config

Limited IP Multicast

Multicast Filtering : 256 profiles and 16 entries per profile

VLAN VLAN Group

Max 4K VLAN Groups

802.1q Tagged VLAN

MAC VLAN : 12 Entries

Protocol VLAN : Protocol Template 16, Protocol VLAN 16

GVRP

VLAN VPN (QinQ)

Port-Based QinQ

Selective QinQ

Voice VLAN

Access Control List Time-based ACL

MAC ACL

Source MAC

Destination MAC

VLAN ID

User Priority

Ether Type

IP ACL

Source IP

Destination IP

Fragment

IP Protocol

TCP Flag

TCP/UDP Port

DSCP/IP TOS

User Priority

Combined ACL

Packet Content ACL

IPv6 ACL

Policy

Mirroring

Redirect

Rate Limit

QoS Remark

ACL apply to Port/VLAN

Security IP-MAC-Port Binding

DHCP Snooping

ARP Inspection

IPv4 Source Guard

IPv6-MAC-Port Binding

DHCPv6 Snooping

ND Detection

IPv6 Source Guard

DoS Defend

Static/Dynamic Port Security

Up to 64 MAC addresses per port

Broadcast/Multicast/Unicast Storm Control

kbps/ratio/pps control mode

IP/Port/MAC based access control

802.1X

Port based authentication

Mac based authentication

VLAN Assignment

MAB

Guest VLAN

Support Radius authentication and accountability

AAA (including TACACS+)

Port Isolation

Secure web management through HTTPS with SSLv3/TLS 1.2

Secure Command Line Interface (CLI) management with SSHv1/SSHv2

IPv6 IPv6 Dual IPv4/IPv6

Multicast Listener Discovery (MLD) Snooping

IPv6 ACL

IPv6 Interface

Static IPv6 Routing

IPv6 neighbor discovery (ND)

Path maximum transmission unit (MTU) discovery

Internet Control Message Protocol (ICMP) version 6

TCPv6/UDPv6

IPv6 applications

DHCPv6 Client

Ping6

Tracert6

Telnet (v6)

IPv6 SNMP

IPv6 SSH

IPv6 SSL

Http/Https

IPv6 TFTP

L3 Features 16 IPv4/IPv6 Interfaces

Static Routing

48 static routes

Static ARP

316 ARP Entries

Proxy ARP

Gratuitous ARP

DHCP Server

DHCP Relay

DHCP L2 Relay

Management Web-based GUI

Command Line Interface (CLI) through console port, telnet

SNMPv1/v2c/v3

Trap/Inform

RMON (1, 2, 3, 9 groups)

SDM Template

DHCP/BOOTP Client

802.1ab LLDP/LLDP-MED

DHCP AutoInstall

Dual Image, Dual Configuration

CPU Monitoring

Cable Diagnostics

EEE

Password Recovery

SNTP

System Log

Advanced Features Support Omada Hardware Controller (OC200/OC300), Software Controller, Cloud-Based Controller

Automatic Device Discovery

Batch Configuration

Batch Firmware Upgrading

Intelligent Network Monitoring

Abnormal Event Warnings

Unified Configuration

Reboot Schedule

ZTP (Zero-Touch Provisioning)*

MIBs MIB II (RFC1213)

Bridge MIB (RFC1493)

P/Q-Bridge MIB (RFC2674)

Radius Accounting Client MIB (RFC2620)

Radius Authentication Client MIB (RFC2618)

Remote Ping, Traceroute MIB (RFC2925)

Support TP-Link private MIBs

RMON MIB(RFC1757, rmon 1,2,3,9)

MANAGEMENT
Omada App Yes, through Omada Cloud-Based Controller (Not Supported by TL-SG2210P v4)

OC300

OC200

Omada Software Controller

Centralized Management Omada Cloud-Based Controller (Not Supported by TL-SG2210P v4)

Omada Hardware Controller OC300

Omada Hardware Controller OC200

Omada Software Controller

Cloud Access Yes, through Omada Cloud-Based Controller (Not Supported by TL-SG2210P v4)

OC300

OC200

Omada Software Controller

Zero-Touch Provisioning Yes. Requiring the use of Omada Cloud-Based Controller (Supported by TL-SG2210P v3.2, v5 and above, while is not supported by TL-SG2210P v4)
Management Features Web-based GUI

Command Line Interface (CLI) through console port, telnet

SNMPv1/v2c/v3

Trap/Inform

RMON (1, 2, 3, 9 groups)

SDM Template

DHCP/BOOTP Client

802.1ab LLDP/LLDP-MED

DHCP AutoInstall

Dual Image, Dual Configuration

CPU Monitoring

Cable Diagnostics

EEE

Password Recovery

SNTP

System Log

OTHERS
Certification CE, FCC, RoHS
Package Contents TL-SG3210 Switch

Power Cord

Quick Installation Guide

Rackmount Kit

Rubber Feet

System Requirements Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7/8/10/11, MAC® OS, NetWare®, UNIX® or Linux.
Environment Operating Temperature : 0–45 ℃ (32–113 ℉);

Storage Temperature : -40–70 ℃ (-40–158 ℉)

Operating Humidity : 10–90% RH non-condensing

Storage Humidity : 5–90% RH non-condensing
