Description

Tplink TL-SL1210MP Dubai

The Tplink TL-SL1210MP Dubai is an unmanaged PoE switch featuring eight 10/100 Mbps ports, one Gigabit port, and one SFP port. It boasts a total PoE budget of 124 W* across its eight PoE+ ports. This smart switch can automatically identify and provide power to all IEEE 802.3af/at compliant Powered Devices (PDs). This innovation enables the transmission of both electrical power and data over a single cable, facilitating network expansion to areas without power lines or outlets. It’s the perfect solution for deploying devices like Access Points (APs), IP Cameras, IP Phones, and more in locations where power access is limited.

Features:

• Eight PoE+ ports for combined data and power transmission over a single cable.
• Compatible with IEEE802.3af/at compliant PDs, expanding your network effortlessly.
• Each PoE port supports up to 30 W of PoE power.
• Total PoE power capacity of 124 W* for all PoE ports.
• Extend** Mode enables data and power transmission of up to 250 meters, perfect for surveillance systems.
• Isolation Mode for one-click client traffic separation, enhancing security and performance.
• No configuration or installation required, simplifying setup.
• Overload Arrangement: The Tplink TL-SL1210MP Dubai features a priority function to protect the system from power overloads. In cases where the total PoE PDs power consumption exceeds 124 W*, the system will prioritize and cut off power to the lowest-priority port.
• Intelligent Power Management: Priority (port 1 > port 2 >…> port 7 > port 8) safeguards the system from overloads. For instance, if ports 1, 2, 3, and 5 are each using 30 W (the maximum power per port), totaling 120 W, and an additional PD is inserted into port 4 requiring 30 W, the system will disable power to port 4 to prevent overloading. This ensures that ports 1, 2, 3, and 4 each receive 30 W while port 5 remains powered.
• User-Friendly: The Tplink TL-SL1210MP Dubai is user-friendly with a straightforward installation process. It requires no configuration or installation. Its desktop and wall-mountable design, coupled with exceptional performance and quality, make the TL-SL1210MP an excellent choice for network expansion.

Technical Details

• Power Over Ethernet (PoE) : PoE+
• PoE Budget1 : 24 W
• Performance
  • Switching capacity: 5.6 Gbps
  • Packet forwarding rate: 4.166 Mbps
• MAC Address Table Size : 2K entries
• Jumbo Frame Support : 16KB
• Features
  • Flow control,
  • Auto-negotiation
  • Auto-uplink (auto MDI/MDI-X)
  • Store and forward
  • Fanless, extend mode
• Compliant Standards
  • IEEE 802.3u
  • IEEE 802.3i
  • IEEE 802.3z
  • IEEE 802.3ab
  • IEEE 802.3af
  • IEEE 802.3x
  • IEEE 802.3at
• Status Indicators
  • Power
  • PoE,
  • Link/activity
  • PoE max

Expansion / Connectivity

Interfaces

• 8 x 100Base-TX RJ-45 PoE+ – 30 W
• 1 x Gigabit LAN SFP
• 1 x 1000Base-T RJ-45

Power

Power Device : External power adapter
