Tplink TL-SX3008F Dubai

Tplink TL-SX3008F Dubai

The Tplink TL-SX3008F Dubai is engineered to enhance your network’s capacity, accommodating numerous high-bandwidth applications, whether in small or large businesses. This JetStream 8-Port SFP+ 10GE Managed Switch is equipped with eight 10G SFP+ ports.

Category:

Description

Tplink TL-SX3008F Dubai

The Tplink TL-SX3008F Dubai is engineered to enhance your network’s capacity, accommodating numerous high-bandwidth applications, whether in small or large businesses. This JetStream 8-Port SFP+ 10GE Managed Switch is equipped with eight 10G SFP+ ports, boasting a robust 160 Gb/s switching capacity and a rapid 119.04 Mbps forwarding rate. It ensures lightning-fast and dependable data transfers over fiber connections, catering to compatible devices like network storage and servers. Additionally, it offers robust Layer 2 functionalities, including support for link aggregation for up to eight groups, each containing eight ports, as well as features like IGMP snooping and port mirroring. The switch prioritizes data security with an array of protective measures, including Access Control List (ACL) support and VLAN support. To conveniently manage your networked devices from a distance, utilize the Omada Software Defined Networking platform through the Omada app.

Features

Centralized Management

The Omada Software Defined Networking (SDN) platform on the Tplink TL-SX3008F Dubai integrates access points, switches, gateways, and other network devices to provide high efficiency, security, and reliability.

Omada App

Configure, manage, and monitor your network devices from almost anywhere in the world using your smartphone or tablet.

Access Control List

Allow or deny connected devices access to data with user-defined network rules.

Optimized Traffic

Configure the switch to prioritize voice and video traffic to help ensure clear calls and smooth media streaming.

VLAN Support

Group devices using VLAN to help improve network security and reduce data congestion.

Security Features

Protect your network from attacks and intrusions with IP-MAC-Port Binding, Access Control List, DoS Defend, Storm control, DHCP Snooping, 802.1x, Radius Authentication, and more.

ISP Features

Internet Service Providers benefit from features such as sFlow, QinQ, L2PT, PPPoE ID Insertion, and IGMP authentication. 802.3ah OAM, and Device Link Detection Protocol (DLDP) to quickly troubleshoot Ethernet links across the network.

IPv6 Support

Built-in IPv6 functionality such as Dual IPv4/IPv6 Stack, MLD Snooping, IPv6 ACL, DHCPv6 Snooping, IPv6 Interface, means that you won’t need to upgrade your hardware when you’re ready to set up a next generation network.

Quiet Operation

The metal chassis of the Tplink TL-SX3008F Dubai allows the switch to operate silently while dissipating heat.

Specifications

Interfaces
Ports 8 x 10Gb SFP+

1 x Ethernet (RJ45) (Console)

1 x Micro-USB (Console)

Protocols
Layer Services Supported Layer 2 Support, Layer 3 Support
Supported Protocols IGMP Snooping

IPv4

IPv6

Link Aggregation

Port Mirroring

Queuing Strict Priority, Weighted Round Robin (WRR)
Jumbo Frames Support 9000 Bytes
MAC Address Table Size 32K
VLAN Groups 4000
Security
Security Features DHCP Snooping

DoS Attack Prevention

RADIUS Authentication

Storm Control

Access Control List 512
Static Routes 48
Standards
Supported IEEE Standards 802.1ab, 802.1d, 802.1p, 802.1s, 802.1w, 802.1x, 802.3ad, 802.3x
Performance
Forwarding Rate 119.04 Mpps
Switching Bandwidth 160 Gb/s (Non-Blocking)
Priority Queues 8
Electrical
Power Draw 15.46 W
AC Input Power 100 to 240 VAC, 50 / 60 Hz
Power Supply Type Internal
Environmental
Operating Temperature 32 to 113°F / 0 to 45°C
Operating Humidity 10 to 90%
Storage Temperature -40 to 158°F / -40 to 70°C
Storage Humidity 5 to 90%
General
Cooling System Passive
Rack Form Factor 1 RU
Dimensions 17.3 x 7.1 x 1.7″ / 440 x 180 x 44 mm
Packaging Info
Package Weight 5 lb
Box Dimensions (LxWxH) 21 x 9.95 x 3.5″
