Tplink TL-WA901ND Dubai

Tplink TL-WA901ND Dubai

The Tplink TL-WA901ND Dubai  supports a host of different functions that makes your wireless networking experience more flexible than ever before.

Category:

Description

Tplink TL-WA901ND Dubai

The TP-LINK Wireless N Access Point Tplink TL-WA901ND Dubai is designed to establish or expand a scalable high-speed wireless N network or to connect multiple Ethernet enabled devices such as game consoles, digital media adapters, printers, or network attached storage devices to a wireless network. The Tplink TL-WA901ND Dubai  supports a host of different functions that makes your wireless networking experience more flexible than ever before. Now, you can enjoy a better Internet experience when downloading, gaming, video streaming or with any other application that you may wish to use.

Highlighted Features:

Enhanced Wireless N Speed & Coverage Incorporating advanced IEEE 802.11n MIMO (Multi Input Multi Output) technology, the Tplink TL-WA901ND Dubai operates seamlessly through three antennas, equipped with intelligent smart antenna technology for simultaneous transmission and reception (Tx and Rx). This innovation triumphs over interference and signal degradation during long-distance journeys or traversing physical obstacles within confined spaces such as small offices or sprawling apartments. The outcome is truly exceptional – a remarkable uplift in wireless performance, even within structures composed of steel and concrete. Notably, this technology ensures reliable wireless network connectivity over extended distances, surpassing the capabilities of legacy 11g products.

Versatile Operating Modes for Effortless WLAN Establishment Empowered by a range of operational modes including AP Client, Bridge, Repeater, and AP, the Tplink TL-WA901ND Dubai caters to diverse wireless applications, enhancing users’ dynamic and comprehensive AP experience. This versatile range of operating modes simplifies the creation of wireless networks, whether in challenging-to-wire locations or areas plagued by wireless dead zones.

Passive PoE Support for Enhanced Deployment Flexibility Distinguished by its compatibility with Passive Power over Ethernet (PoE), the Tplink TL-WA901ND Dubai can concurrently transmit data and electricity through an Ethernet cable, reaching up to an impressive 100 feet from the source. This distinctive feature amplifies your deployment options, allowing strategic AP placement for optimal signal reception – whether mounted on a wall or suspended from the office ceiling.

Technical Specs

HARDWARE FEATURES
Interface
  • One 10/100M Ethernet Port(RJ45)
  • Support Passive PoE
Button WPS/Reset, Power On/Off
Power Consumption 5.8W
External Power Supply 12VDC/1A
Wireless Standards IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Dimensions ( W x D x H ) 7.67*5.12*1.43 in.( 194.82*129.93*36.2mm)
Antenna Type 3*5dBi Detachable Omni Directional (RP-SMA)
WIRELESS FEATURES
Frequency 2.4-2.4835GHz
Signal Rate
  • 11n : Up to 450Mbps(dynamic)
  • 11g : Up to 54Mbps(dynamic)
  • 11b : Up to 11Mbps(dynamic)
Reception Sensitivity
  • 270M : -68dBm@10% PER
  • 130M : -68dBm@10% PER
  • 108M : -68dBm@10% PER
  • 54M   : -68dBm@10% PER
  • 11M   : -85dBm@8% PER
  • 6M     : -88dBm@10% PER
  • 1M     : -90dBm@8% PER
Transmit Power EU version <20dBm
Wireless Modes Access Point /Repeater (Range Extender)/ Bridge with AP/ Client/Multi-SSID/
Wireless Functions
  • Enable/Disable Wireless Radio;
  • WMM (Wi-Fi Multimedia)
  • Wireless MAC Address Filtering
  • Wireless Statistic
  • Domain Login Function
Wireless Security 64/128/152-bit WEP / WPA / WPA2,WPA-PSK / WPA2-PSK
DHCP DHCP Server
Quality of Service WMM
Management SNMP
Advanced Functions Up to 30 meters PoE is supported
OTHERS
Certification CE, RoHS
Package Contents
  • Wireless Access Point TL-WA901ND
  • 3 Detachable Omni Directional Antennas
  • Power Supply Unit
  • Passive PoE Power Injector
  • Resource CD
  • Quick Installation Guide
  • RJ-45 Ethernet Cable
System Requirements Microsoft Windows XP, Vista, Windows 7, 8, 10
Environment
  • Operating Temperature : 0℃~40℃ (32℉~104℉)
  • Storage Temperature : -40℃~70℃ (-40℉~158℉)
  • Operating Humidity : 10%~90% non-condensing
  • Storage Humidity : 5%~90% non-condensing
