Yealink VC500 Dubai

The Yealink VC500 Dubai is a compact and powerful video conferencing system from Yealink. It is designed for small to medium-sized conference rooms and enables high-quality video and audio communication. The system includes a 1080P PTZ camera with a 83-degree field of view and 5x optical zoom, providing clear and detailed images of participants. The included conference phone has a built-in microphone and speaker, offering HD audio and echo cancellation technology for crisp and clear sound. The Yealink VC500 Dubai also supports dual-screen display and content sharing, allowing for efficient collaboration and presentations.

The system is easy to set up and use, with a user-friendly interface and remote control. It supports various protocols and standards, including H.323 and SIP, and can be integrated with other video conferencing platforms. The Yealink VC500 Dubai is also compatible with various cloud services, such as Zoom and Microsoft Teams, making it a versatile solution for various collaboration scenarios.

In terms of security, the Yealink VC500 Dubai uses advanced encryption technology to protect communication and data. It supports multiple authentication methods, including 802.1x, TLS, and SRTP, ensuring secure and reliable conferencing.

The Yealink VC500 Dubai is designed for flexibility and scalability, with optional expansion microphones and wireless microphones available to support larger rooms and more participants. It also supports various network connectivity options, including wired and wireless connections, making it easy to deploy in various environments.

Overall, the Yealink VC500 Dubai is an excellent solution for small to medium-sized conference rooms, offering high-quality video and audio communication and a user-friendly interface. Its compatibility with various cloud services and protocols makes it a versatile solution for various collaboration scenarios, while its advanced security features ensure secure and reliable communication. The optional expansion microphones and network connectivity options also make it a flexible and scalable solution for growing businesses.

Yealink VC500 Specifications

Package includes:

•  VC500 Codec（integrate camera）
•  CP960 Conference Phone with 2 Wired Expansion Mics Or 2 × Wireless Microphones with DD10 DECT Dongle
•  Cable Hub VCH50
•  Remote Control VCR11
•  Cable Bundle
• Full-HD PTZ Camera
•  1920 x 1080 video resolution
•  60 frame rate (VC500 Pro)
•  5x optical zoom PTZ camera
•  Horizontal field of view: 83°
•  Vertical field of view: 52°
•  Pan angel range: +/- 30°
•  Tilt angel range: +/- 20°
•  Beauty shot

Video Standard and Network Suitability

•  Video codecs:
• H.265/HEVC (VC500 Pro), H.264 High Profile, H.264, H.263
•  Forward Error Correction (FEC)
•  Anti 30% video packet loss
•  Bandwidth dynamic adaptive adjustment
•  Shared content and audio preference strategy
•  Bandwidth/protocol/ auto adaptive

Audio Features

•  Audio codecs:
  •  Opus, 8~48kHz sampling rate
  •  14kHz bandwidth with G.722.1C
  •  7kHz bandwidth with G.722.1
  •  3.4kHz bandwidth with G.711 (PCMA/PCMU)
•  Audio technology:
  •  Acoustic echo cancellation
  •  Automatic gain control
  •  Yealink Noise Proof Technology
  •  CNG, PLC, AJB, De-Rerb
• VCS Phone CP960 (VC500-Phone)
•  Built-in 3-microphone array
•  20ft/360° voice pickup range
•  2 x CP Wired Expansion Mic
•  Harman speaker
•  5-inch touchscreen with 1280*720 resolution
• CPW90 Wireless Microphone KIT (VC500-Wireless Micpod)
•  DECT Technology
•  800mAh battery capacity
•  24-hour talking time
•  12-day standby time
•  Indoor range: 50m
•  Outdoor Range: 300m (in ideal conditions)
•  10-foot (3-meter) 360° voice pickup
•  Mute the microphone with touchpad

Call Features

•  1080p60 people + 1080P30 content sharing
• video quality
•  Video Layout: Picture-in-picture (PIP)
•  Video/audio recording and playback
•  Dual displays and ‘focus’ feature
•  Screenshots in USB flash drive
•  Group dial
  •  YMS meeting control:
  • invite/remove
  • mute/unmute participates
  • lock
•  DND (do not disturb), call statistics
•  Auto answer, mute, and call waiting
•  Virtual keyboard
•  Local directory: 500 entries
•  Call history: all/missed/received/dialed
•  LDAP phonebook
•  Multi-language support

Network and Security Features

•  IPv4 and IPv6, DHCP/static IP
•  HTTP/HTTPS web server
•  RS232/HTTP API for control system integration
•  SRTP/TLS, AES 128-bit encryption
•  QoS: 802.1p/q, Diff-serv
•  VLAN, IEEE802.1X, LLDP-MED
•  Anti-attack
•  Network diagnosis: Ping, trace route
•  Time and date synchronization using SNTP
•  Built-it certificate
• NAT and Firewall Traversal
•  ICE/TURN/STUN
•  H.460
•  NAT (manual/auto mode)
•  Yealink intelligent firewall traversal
•  Open VPN
• VC500 Codec Connections
•  2 x HDMI output
•  1 x Yealink extension port (RJ-45) connect to
• VCH50 /CP960 Phone
•  1 x 10/100/1000M Ethernet port
•  2 x USB 2.0
•  1 x Power port
•  1 x Security lock slot
•  1 x Reset slot
• VCH50 Connections
•  1 x RJ45 port connect to VC500 codec
•  1 x RJ45 port connect to CP960
•  1 x HDMI input for content sharing (with audio)
•  1 x Mini-DP input for content sharing (with audio)
•  1x USB 2.0 for recording

Other Physical Features

•  External Yealink Power Adapter: AC 100~240V input and DC 48V/0.7A Output
•  Wall/TV mounted shelf with screws
•  Power consumption (PSU):
• Idle＜7.8W, normal operating: 8W; MAX: 11.8W
•  Dimension (W.D.H):
  •  VC500 codec: 300 mm x 99 mm x 165.3 mm
  •  CP960: 338mm x 338mm x 74mm
  •  VCR11: 190mm x 55mm x 24mm
•  Operating humidity: 10~95%
•  Operating temperature: 0~40°C
•  Storage temperature: -30~70°C
• Package Features
•  N.W/CTN: 6.6 kg
•  G.W/CTN: 7.8 kg
•  Giftbox size: 385mm x 290mm x 245mm
