Yealink VC800 Dubai
Yealink VC800 Dubai - Image 2

Yealink VC800 Dubai

Yealink VC800 Dubai

The Yealink VC800 Dubai Video Conferencing System from Yealink is a premium endpoint designed for large conference rooms and boardrooms. It features a powerful codec that supports H.265/HEVC video compression.

Category:

Description

Yealink VC800 Dubai

The Yealink VC800 Dubai is a powerful and versatile video conferencing system designed to meet the needs of large meeting rooms and boardrooms. It supports a wide range of video and audio codecs, including H.265/HEVC, H.264 High Profile, and Opus, enabling it to deliver high-quality audio and video with minimal bandwidth requirements.

The system features a PTZ camera with a 12x optical zoom and a 1080p60 resolution, providing clear and detailed images of participants in the room. It also has a wide-angle lens with a 78-degree field of view, making it easy to capture all participants in the room. The camera can be controlled using the remote control, allowing users to pan, tilt, and zoom the camera as needed.

In addition to the camera, the Yealink VC800 Dubai system includes a codec, a microphone array, and a speaker. The codec is the heart of the system, providing the processing power needed to encode and decode audio and video streams. It also provides connectivity options, including HDMI, VGA, and USB ports, allowing users to connect laptops, tablets, and other devices to the system.

The microphone array is designed to capture audio from all directions, ensuring that everyone in the room can be heard clearly. It features built-in noise reduction technology, which helps to eliminate background noise and improve voice clarity. The speaker is also designed to provide high-quality audio, with support for full-duplex audio, echo cancellation, and automatic gain control.

The Yealink VC800 Dubai system is easy to set up and use, with a user-friendly interface that can be accessed using the remote control or the touch panel. The touch panel is an optional accessory that provides a more intuitive interface for controlling the system, with a large, high-resolution display and intuitive touch-based controls.

One of the key features of the Yealink VC800 Dubai system is its support for dual displays. This allows users to connect two displays to the system, enabling them to view content on one screen while video conferencing on the other. This is particularly useful in large meeting rooms and boardrooms, where multiple displays can help to improve collaboration and productivity.

The Yealink VC800 Dubai system also supports a wide range of collaboration features, including screen sharing, whiteboarding, and document sharing. Users can share content from their laptops or other devices using the HDMI or VGA ports, or they can share content wirelessly using the built-in Wi-Fi module.

The system is designed to be highly secure, with support for encryption protocols like TLS and SRTP, as well as support for LDAP and H.235 authentication. It also has built-in firewall traversal technology, which allows it to work seamlessly with firewalls and other network security devices.

Yealink VC800 Specifications

Package includes:

  •  VC800 Codec（integrate camera）
  •  CTP20 Collaboration Touch Panel
  •  2 x VCM34 Video Conferencing Microphone Arrays
  •  VCR11 Remote Control
  •  VCH50 Video Conferencing Hub (optional)
  •  WPP20 Wireless Presentation Pod (optional)
  •  Cable Bundle

Full-HD PTZ Camera

  •  1920 x 1080 video resolution
  •  60 frame rate
  •  12x optical zoom PTZ camera
  •  Horizontal field of view: 70°
  •  Vertical field of view: 42°
  •  Pan angel range: +/- 100°
  •  Tilt angel range: +/- 30°
  •  Beauty shot

Multipoint Capacity

  •  Built-in multipoint up to 24 sites at 1080p30
  •  Multipoint license for 8/16/24 sites
  •  Supports two virtual meeting rooms
  •  Additional five-way audio call
  •  Mixed protocols, codecs, bandwidth, resolution and frame rate

Video Standard and Network Suitability

  •  Video codecs:
  • H.265/HEVC, H.264 High Profile, H.264, H.263
  •  Bandwidth dynamic adaptive adjustment
  •  Forward Error Correction (FEC), anti 30% video
  • packet loss and 70% audio packet loss
  •  Shared content and audio preference strategy
  •  Bandwidth/protocol/ auto adaptive

Audio Features

  •  Audio codecs:
  •  ARES
  •  Opus, 8~48kHz sampling rate
  •  14kHz bandwidth with G.722.1C
  •  7kHz bandwidth with G.722.1
  •  3.4kHz bandwidth with G.711 (PCMA/PCMU)
  • Audio technology:
  •  Acoustic echo cancellation
  •  Automatic gain control
  •  Yealink Noise Proof Technology
  •  CNG, PLC, AJB, De-Rerb

Collaboration Touch Panel CTP20

  •  13.3 inch IPS FHD 1080P capacitive touch screen
  •  Supports active pressure capacitance touch pen

Video Conferencing Microphone Array VCM34

  •  Built-in 3 microphone array
  •  20ft/360°voice pickup range
  •  Up to 4 VCM34 in one system

Call Features

  •  1080p60 people + 1080P30 content sharing video quality
  •  Video Layout:
    •  Voice activation (onePlusN)
    •  onePlusN, maximum 1+7 viewable participates
    •  N*N, maximum 3*3 viewable participates
    •  Picture-in-picture (PIP) , full-screen
    • Video/audio recording and playback
  •  Dual displays and ‘focus’ feature
  •  Screenshots in USB flash drive
  •  Group dial
  •  Meeting control:
    •  invite/remove
    •  mute/unmute participates (only for Yealink Meeting Server)
  •  DND (do not disturb), call statistics
  •  Auto answer, mute, and call waiting
  •  Virtual meeting room password
  •  Virtual keyboard
  •  Local directory: 500 entries
  •  Call history: all/missed/received/dialed
  •  LDAP phonebook
  •  Multi-language support

Network and Security Features

  •  IPv4 and IPv6, DHCP/static IP
  •  HTTP/HTTPS web server
  •  RS232/HTTP API for control system integration
  •  SRTP/TLS, AES 256-bit encryption
  •  QoS: 802.1p/q, Diff-serv
  •  VLAN, IEEE802.1X, LLDP-MED
  •  Anti-attack
  •  Network diagnosis: Ping, trace route
  •  Time and date synchronization using SNTP
  •  Built-in certificate

NAT and Firewall Traversal

  •  NAT (manual/auto mode)
  •  ICE/TURN/STUN
  •  Yealink intelligent firewall traversal
  •  Open VPN
  •  H.460

VC800 Codec Connections

  •  2 x HDMI output (supporting CEC function)
  •  1 x Line-in (3.5mm)
  •  1 x Line-out (3.5mm)
  •  1 x Yealink extension port (RJ-45) connect to
  • VCH50/VCM34
  •  1 x 10/100/1000M Ethernet port
  •  2 x USB 2.0
  •  1 x Power port
  •  1 x Security lock slot
  •  1 x Reset slot

VCH50 Connections

  •  1 x RJ45 port connect to VC800 codec
  •  1 x RJ45 port connect to VCM34
  •  1 x HDMI input for content sharing (with audio)
  •  1 x Mini-DP input for content sharing (with audio)
  •  1x USB 2.0 for recording

Other Physical Features

  •  Color: Space Silver
  •  External Yealink Power Adapter:
  • AC 100~240V input and DC 48V/0.7A Output
  •  Wall/TV mounted shelf with screws
  •  Power consumption (PSU):
  • Idle＜16W, normal operating: 17W; MAX: 21W
  •  USB Output: 5V 1A
  •  Dimension (W.D.H):
    •  VC800 codec: 235 mm x 172 mm x 169 mm
    •  CTP20: 321.5mm x 118mm x 196mm
    •  VCM34: 169mm x 171.5mm x 37.5mm
    •  VCR11: 190mm x 55mm x 24mm
  •  Operating humidity: 10~95%
  •  Operating temperature: 0~40°C
  •  Storage temperature: -30~70°C

Package Features

  •  N.W/CTN: 6.6 kg
  •  G.W/CTN: 7.8 kg
  •  Giftbox size: 414mm*402mm*384mm
