The Yeastar TG1600 Dubai is a VoIP GSM gateway that allows users to connect their IP-based communication systems to the GSM network. It supports up to 16 channels and can handle both inbound and outbound calls.

Category:

Description

Yeastar TG1600 Dubai

The Yeastar TG1600 Dubai is a high-performance VoIP GSM gateway designed for small to medium-sized businesses. It is a cost-effective solution that enables companies to connect their IP-based communication systems to the GSM network. The Yeastar TG1600 Dubai supports up to 16 channels, allowing for concurrent calls on multiple lines. This makes it ideal for businesses that require a reliable and efficient communication system.

One of the main advantages of the Yeastar TG1600 Dubai is its flexibility. The device can be configured to work with a wide range of IP-PBX systems, allowing businesses to integrate their existing communication infrastructure seamlessly. It supports SIP and IAX2 protocols, which are widely used in the VoIP industry. Additionally, the gateway offers advanced call routing features, such as least cost routing, to help businesses reduce their communication costs.

The Yeastar TG1600 Dubai also supports SIM card rotation, which is a unique feature that allows users to rotate multiple SIM cards automatically. This is particularly useful for businesses that make a large number of outbound calls, as it helps to distribute the call traffic evenly across multiple SIM cards. The device also supports SMS sending and receiving, allowing businesses to use text messaging for marketing, customer engagement, and other purposes.

Another key feature of the Yeastar TG1600 Dubai is its web-based user interface, which provides remote access to the device. This allows users to manage and configure the gateway from anywhere in the world, using a web browser. The user interface is user-friendly and provides access to all the features of the gateway, including call routing, SIM card rotation, and SMS messaging.

In terms of call quality, the Yeastar TG1600 Dubai offers excellent voice clarity and reliability. It uses advanced voice codecs, such as G.711 and G.729, which provide high-quality voice transmission over the internet. The device also supports echo cancellation and jitter buffer, which helps to eliminate any delays or distortion during calls.

Overall, the Yeastar TG1600 Dubai is an excellent choice for businesses looking to integrate their VoIP and GSM communication systems. It offers a range of advanced features, including call routing, SIM card rotation, and SMS messaging, all at an affordable price point. Its flexibility, reliability, and ease of use make it an ideal solution for businesses of all sizes.

Yeastar TG1600 Specifications

Interface

  •  TG800: 8 GSM or 3G or 4G Channels
  •  TG1600: 16 GSM or 3G Channels
  •  TG800, TG1600: 2 10/100 Mbps Ethernet Interfaces
  •  Optional Antenna Splitter (4 in 1 antenna): TG400, TG800, TG1600

Voice Processing

  •  Protocol: SIP, IAX2
  •  Transport: UDP, TCP, TLS, SRTP
  •  Voice Codec: G.711 (alaw/ulaw), G.722,G.726, G.729A, GSM, ADPCM, Speex
  •  Echo Cancellation: ITU-T G.168 LEC
  •  DTMF Mode: RFC2833, SIP INFO, In-band
  •  SIP Server for IP Phones Included
  •  SIP Response Code Switch
  •  Call Progress Tone Generation
  •  1 Stage/2 Stage Dial



System Features

  •  Mobile Ports Groups
  •  VoIP Trunk Group
  •  Incoming /Outgoing Routing rules
  •  Call Blocklist
  •  Hotline
  •  AutoCLIP
  •  Call Duration Limitation
  •  Call Transfer
  •  Call Back
  •  Call Detail Record (CDR)
  •  Call Status Display
  •  NTP
  •  IP Blocklist
  •  Network Attack Alert
  •  Packet Capture
  •  System Logs

Mobile Features

  •  GSM Frequency: 850/900/1800/1900MHz
  •  WCDMA Frequency: 850/1900MHz,850/2100MHz, 900/2100MHz
  •  4G LTE Band: depends on the module type
  •  VoLTE if the Carrier Supports
  •  SMS Sending and Receiving
  •  Send Bulk SMS
  •  SMS Center
  •  Gain Adjustment
  •  USSD
  •  PIN Modify
  •  Carrier Selection: Auto/Manual
  •  Talk Time Alarm
  •  Caller ID/CLIR
  •  Open API for SMS and USSD

Network & Management

  •  Network Protocol: FTP, TFTP, HTTP, SSH
  •  NAT Traversal: Static NAT, STUN
  •  Static Route
  •  OpenVPN
  •  Firewall
  •  VLAN
  •  QoS/ToS
  •  DDNS
  •  Configure Backup/Restore
  •  Firmware Upgrade by HTTP/TFTP
  •  Web based Configuration

Physical

  • Model Size (mm) Power Supply
  • TG800 340x210x44 AC 100-240V
  • TG1600 440x280x44 AC 100-240V
  •  Operation Range: 0°C to 40°C, 32°F to 104°F
  •  Storage Range: -20°C to 65°C, -4°F to 149°F
  •  Humidity: 10-90% non-condensing
