Yeastar TG800 Dubai is a VoIP GSM/3G/4G gateway that allows businesses to integrate their traditional telephone system with mobile networks for better communication. With support for up to 8 SIM cards.

Category:

Description

Yeastar TG800 Dubai

Yeastar TG800 Dubai is a VoIP GSM/3G/4G gateway designed to provide seamless integration between traditional telephone systems and mobile networks. It is a highly reliable and cost-effective solution that enables businesses to leverage the benefits of mobile networks while retaining the convenience and features of their existing phone systems.

The device supports up to 8 SIM cards, which means that it can connect to multiple mobile networks simultaneously. This ensures that businesses can have a reliable and uninterrupted communication channel, even if one network is down or experiencing issues. The Yeastar TG800 Dubai also supports a range of voice codecs, including G.711A, G.711U, G.729A, and more, to ensure the highest call quality.

One of the main advantages of the Yeastar TG800 Dubai is its ability to route incoming and outgoing calls through the most cost-effective channels. This is especially beneficial for businesses that make a lot of international or long-distance calls, as it can significantly reduce communication costs. The device also supports advanced features such as call forwarding, call waiting, caller ID, and more, which enhance the overall communication experience for users.

The Yeastar TG800 Dubai is a highly versatile solution that can be used in a variety of settings, including offices, call centers, retail stores, and more. It is also incredibly easy to set up and manage, thanks to its intuitive web-based user interface. This allows businesses to configure and customize the device according to their specific requirements, and monitor its performance in real-time.

In terms of security, the Yeastar TG800 Dubai comes equipped with advanced encryption protocols, including TLS, SRTP, and HTTPS, to ensure that all communication is secure and protected from unauthorized access. The device also supports a range of network protocols, including SIP, IAX2, and H.323, which make it compatible with a wide range of PBX systems and softphones.

Overall, the Yeastar TG800 Dubai is a highly reliable, cost-effective, and versatile VoIP GSM/3G/4G gateway that provides businesses with seamless integration between traditional telephone systems and mobile networks. Its advanced features, easy management, and robust security protocols make it an ideal solution for businesses of all sizes and types.

Yeastar TG800 Specifications

Interface

  •  TG800: 8 GSM or 3G or 4G Channels
  •  TG1600: 16 GSM or 3G Channels
  •  TG800, TG1600: 2 10/100 Mbps Ethernet Interfaces
  •  Optional Antenna Splitter (4 in 1 antenna): TG400, TG800, TG1600

Voice Processing

  •  Protocol: SIP, IAX2
  •  Transport: UDP, TCP, TLS, SRTP
  •  Voice Codec: G.711 (alaw/ulaw), G.722,G.726, G.729A, GSM, ADPCM, Speex
  •  Echo Cancellation: ITU-T G.168 LEC
  •  DTMF Mode: RFC2833, SIP INFO, In-band
  •  SIP Server for IP Phones Included
  •  SIP Response Code Switch
  •  Call Progress Tone Generation
  •  1 Stage/2 Stage Dial



System Features

  •  Mobile Ports Groups
  •  VoIP Trunk Group
  •  Incoming /Outgoing Routing rules
  •  Call Blocklist
  •  Hotline
  •  AutoCLIP
  •  Call Duration Limitation
  •  Call Transfer
  •  Call Back
  •  Call Detail Record (CDR)
  •  Call Status Display
  •  NTP
  •  IP Blocklist
  •  Network Attack Alert
  •  Packet Capture
  •  System Logs

Mobile Features

  •  GSM Frequency: 850/900/1800/1900MHz
  •  WCDMA Frequency: 850/1900MHz,850/2100MHz, 900/2100MHz
  •  4G LTE Band: depends on the module type
  •  VoLTE if the Carrier Supports
  •  SMS Sending and Receiving
  •  Send Bulk SMS
  •  SMS Center
  •  Gain Adjustment
  •  USSD
  •  PIN Modify
  •  Carrier Selection: Auto/Manual
  •  Talk Time Alarm
  •  Caller ID/CLIR
  •  Open API for SMS and USSD

Network & Management

  •  Network Protocol: FTP, TFTP, HTTP, SSH
  •  NAT Traversal: Static NAT, STUN
  •  Static Route
  •  OpenVPN
  •  Firewall
  •  VLAN
  •  QoS/ToS
  •  DDNS
  •  Configure Backup/Restore
  •  Firmware Upgrade by HTTP/TFTP
  •  Web based Configuration

Physical

  • Model Size (mm) Power Supply
  • TG800 340x210x44 AC 100-240V
  • TG1600 440x280x44 AC 100-240V
  •  Operation Range: 0°C to 40°C, 32°F to 104°F
  •  Storage Range: -20°C to 65°C, -4°F to 149°F
  •  Humidity: 10-90% non-condensing
